:: Center Bulkhead :: C enter Bulkhead - - Bag 9.1
81582
RC8B4e
Motor Mount,
Lower
x2 x2
81114
Engine Mount
Washer
81262 x2 x2
4x10mm
FHCS
:: :: Radio Tray Radio Tray Build Build - - Bag 10.1, 11.1 - Step 1
!
Install servo
splines toward
41094
front of buggy!
3x14mm
(not included)
LP SHCS
31518
2.5x4mm
(not included)
Box, Lower
Receiver Box
Wire clip fits
!
under this foot!
Bag 9.1 - Step 3 - Step 3
x4 x4
Install servo mount wire clip
1st, then the receiver box to
the chassis
FHCS
2
81572
RC8B4e
Receiver
1
81572
RC8B4e
Wire Clip
89454
Optional!
3x12mm
30mm fan
(not included) SHCS
!
Fan, motor, and pinion
not included.
If installing a fan, attach
before installing motor
mounts.
Hardware not included.
Maximum screw depth 4mm.
81572
RC8B4e
Servo Mount
Wire Clip
!
x2 x2
Motor Mount,
4x12mm
