Time Electronics
7016 Pressure Calibrator
1.4
Options
For the 7016, input pressure for regulation can be provided by a compressor or gas cylinder.
When used as a measuring instrument in the field, pressure can be generated by pumps like
the 7090 pneumatic hand pump (vacuum to 40 bar). The 7090 is compact with comfortable
handles with grips molded into the design make it easy to control the instrument whilst
pumping up to pressure. Also available are a range of pumps suitable for workshop use, that
feature an ergonomic mode of operation. These models include the 7193 (vacuum to 40 bar
pneumatic) and 7192 (vacuum to 25 bar pneumatic).
For process control signal simulation a practical tool like the Time Electronics handheld 7006
Loop-Mate is available as an option. It is a low cost, simple operation unit that provides 4 -
20 mA and 0 - 10 V signals at levels of 0 %, 10 %, 25 %, 50 %, 75 %, 90 %, 100 %.
It can also step through these set points automatically to allow hands-free calibration. It is
battery powered and compact, pocket sized and easy to carry in the field.
EasyCal Calibration Software
The 7016 can be controlled with readback via Time Electronics EasyCal software to
automate the calibration process. This provides increased speed of calibration and
consistency of results. Produce traceable calibration certificates and test reports for quality
standards with additional uncertainty information for ISO 17025 conformance.
1.5
Ordering Information
7016 .......... Regulated Low Pressure Calibrator (+ pressure range code a shown below).
Range (bar)
Vacuum
Option Code
Calibration Certificates and Accompanying Products
7090 .......... Pneumatic Hand Pump (vacuum to 40 bar). See datasheet for options.
7192 .......... Pneumatic Benchtop Pump (vacuum to 25 bar). See datasheet for options.
7198 .......... Pressure calibration adaptors/fittings kit. See datasheet for options.
7006 .......... Loop-Mate 1: Loop Current Simulator
ECFL ......... EasyCal Calibration Software. See datasheet for further information.
C178 ......... Traceable calibration certificate (Factory)
C190 ......... Accredited calibration certificate (ISO 17025)
0.2
7111
7100
2
7101
6
User Manual
5
10
7102
7103
