TMT Automation Armstrong Manual page 17

Setting Function
F3
Pedestrian mode
Flashing light – Pre
F4
F5
Ph1 Photocells mode
F6
Ph2 Photocells mode
F7
Buzzer
F8
Latch release mode
F9
Courtesy light
H1
A Button
Paramters
F3-0
F3-1
F3-2
F3-3
F3-4
F3-5
F3-6
F3-7
F3-8
F4-0
F4-1
F4-2
F4-3
flashing F4-4
F4-5
F4-6
F4-7
Please refer to Safety device logic
Please refer to Safety device logic
F7-0
F7-1
F8-0
F8-1
F8-2
F9-0
F9-1
F9-2
F9-3
F9-4
F9-5
F9-6
F9-7
F9-8
F9-9
H1-0
H1-1
H1-2
H1-3
H1-4
H1-5
H1-6
H1-7
H1-8
H1-9
17
Description
10%
20%
30%
40%
50%
60%
70%
80%
90%
0 second (default setting)
1 second
2 second
3 second
4 second
6 second
8 second
10 second
OFF (default setting)
ON
Function OFF (default setting)
Latch function ON
Latch function ON with reverse for
1 second
OFF (default setting)
5 seconds
10 seconds
20 seconds
30 seconds
40 seconds
60 seconds
80 seconds
100 seconds
120 seconds
Function OFF
Step by step Open/Stop/Close/Stop
(default setting)
Open/Stop/Close
Ped mode
Open
Stop
Close
Lamp
Auto-closing switch
Holiday mode switch
