6. Safety Device Logic

• F5 PH1 functions
Paramter
F5-0
(Default setting)
F5-1
F5-2
F5-3
Function
PH1 function OFF
Photocell-Close
Photocell-Open
Safety edge
12
Gate Status
No function
Gate fully close
Gate fully open
Stop during cycle
Closing phrase
Opening phrase
Gate fully close
Gate fully close
Stop during cycle Not allow to Open/close
Closing phrase
Opening phrase
Gate fully close
Gate fully open Reload auto-closing time
Stop during cycle Not allow to Open/close
Closing phrase
Opening phrase
Reaction
No function
Not allow to open
Fast closing
Not allow to close
Open
No effect
Not allow to open
Not allow to close
No effect
Close
Not allow to open
Open for 2 seconds
Close for 2 seconds
