INDEX General Safety Precaution Installation A. Standard Installation B. Dimension Chart C. Motor Fixing D. Wire Connection E. Led Indicator Reaction F. Emergency Release Technical Features A. Technical Feature B. Dimension Limit switch adjustment Maintenance...
(11) Only command the remote when you have a full view of the gate. TMT Automation Inc. shall not be liable for any injury, damage, or any claim to any person or property which may result from improper use or installation of this system.
190mm. **Please make sure “B” and “A” are similar or the same in value that the leaves can be operated smoothly, also to reduce the burden of the motor. Mastiff 400 dimension chart 120 130 140 150 160 170 180 >120°...
MOTOR FIXING Assemble the rear bracket and fix it on the pillar. Remove the wire cover and fix the rear bracket with the pin. Release the gate opener and place the pin into the fitting position no.1 and no. 2 no.1 no.2 Make sure the gate openers are mounted in horizontal position especially in those positions.
Page 7
Wire connection_Open inward Left Motor Right Motor Motor+ Motor+ Motor- Motor- Limit1 Limit1 Limit2 Limit2 White Yellow Black Green Blue White Yellow Black Green Blue Limit 1/3 Limit 2/4 Limit 1/3 Limit 2/4 Lmt1 Lmt2 Lmt3 Lmt4 Terminals of the CB19 control panel Wire connection_Open Outward Left Motor Right Motor...
EMERGENCY RELEASE In case of power failure, push the lid of release chamber and move forward. Insert the key and turn clockwise to unlock, then turn around the knob to release. To restore the automation, simply reverse the above procedures. Step1.
1.4 Limit switch adjustment 1. Remove the screw on the anti-shaking ring 2. Turn the anti-shaking ring 4. Adjust two Knobs to set the open and close position 3. Remove the upper-cover of the outer tube and reveal two Knobs of the front and rear limit switch Opening position: 1.
