Quick Reference Table

Jumper
JBT1
UID SW
LED
LED7
LED1
LED8
Connector
JL1
JSATA1
JNCSI1
JPWR2
JPWR3
JF1
BT1
M.2-C1/M.2-C2
NVMe0~11
NVMe12~15, SATA0~15
JIPMB1
DIMMA1~DIMML1
FAN1~FAN6
AIOM1~AIOM2
JFP1
LWIO/ RWIO
IPMI LAN
JTPM1
PWRI2C
COM1
VGA
JSEN1
USB0/1
USB4/5
Note: Jumpers, connectors, switches, and LED indicators that are not described in the
preceding tables are for manufacturing testing purposes only, and are not covered in this
manual.
Description
CMOS Clear
Unit ID Switch (Push-Button Toggle Switch ON/OFF)
Description Status
Power LED Solid Green: Power On
Green: Blinking (BMC Normal)
BMC Heartbeat LED
Green: Fast Blinking (BMC Initializing)
UID LED Blue: UID Activated
Description
Chassis Intrusion Header
3-Pin Connector for HDD Use
NCSI Connector
12V 8-Pin CPU Core Power Supply Connector
24-Pin ATX Power Supply Connector
Front Control Panel Header
Onboard Battery
M.2 PCIe Interfaces
NVMe Ports
NVMe/SATA Hybrid Ports
4-Pin BMC External I C Header (For an IPMI-Supported Card)
2
DIMM Slots
System Cooling Fans
Supermicro® Advanced I/O Module (AIOM) Slots
Front Control Panel Header 1
Riser Slots
RJ45 Dedicated IPMI LAN Port
TPM (Trusted Platform Module)/Port 80
Power Supply SMBus I2C Header
Rear Panel COM Port #1
Rear Panel VGA Port
Inlet Sensor Header
USB 2.0 Ports
USB 3.0 Ports
17
Chapter 1: Introduction
Default Setting
Open (Normal)
Off
