Item Description
1 PCIe 5.0 x16 slot: full-height, half-length
2 PCIe 5.0 x16 slot: full-height, half-length
PCIe 5.0 x16 OCP 3.0 AIOM slot (NCSI)
A1
PCIe 5.0 x16 OCP 3.0 AIOM slot
A2

Power Supply Indicator

LED Color and State
Solid Green
Blinking Green
Blinking Amber
Solid Amber
Off
Expansion Card Slots
Power Supply Indicator
Power Supply Condition
Indicates that the power supply is on
Indicates that the power supply is plugged in and turned off by the system.
Indicates that the power supply has a warning condition and continues to operate.
Indicates that the power supply is plugged in, and is in an abnormal state. The
system might need service. Please contact Supermicro technical support.
No AC power to modules
