Rear View - Supermicro A+ Server AS-1115CS-TNR User Manual

Color, Status
Red, solid, with Power LED blinking
green
Blue and red, blinking at 10 Hz
Blue, solid
Blue, blinking at 1Hz
Blue, blinking at 2Hz
Blue, blinking at 4Hz
Blue, blinking at 10Hz with Power LED
blinking green

Rear View

Power Supplies
Feature
Power Supplies
VGA Port
USB Ports
COM Port
UID LED
Dedicated BMC LAN Port
Information LED
Description
Fault detected
Recovery mode
UID has been activated locally to locate the
server in a rack environment.
UID has been activated using the BMC to locate
the server in a rack environment.
BMC is resetting
BMC is setting factory defaults
BMC/BIOS firmware is updating
2
A2
Figure 1-3. System: Rear View
System Features: Rear
Description
Two redundant power supply modules
Video port,
When the UID LED is on, the rear VGA may be disabled to enable the front VGA
port, if available.
Two USB 3.0 ports
Serial port
Unit identifier indicator light
BMC LAN port (for indicator details, see
12
BMC LAN Port
VGA Port UID LED
USB Ports COM Port
BMC LAN LEDs)
