Procom MN100TPA-B Owner's Operation And Installation Manual page 13

Test Gauge
Connection*
Sediment
Trap
* Purchase the optional CSA design-certified equipment
shutoff valve from your dealer.
Propane
From External
Regulator (11"
W.C.** to 14" W.C.
Pressure)
200049-02A
INSTALLATION
Ground
Joint Union
Tee Joint
Reducer
Bushing to
1/8" NPT
1/8" NPT
Plug Tap
Tee Joint
Pipe Nipple
Gap
Figure 12 - Gas Connection
Propane
Supply Tank
Figure 13- External Regulator
with Vent Pointing Down
www.usaprocom.com
3/8" NPT
Pipe Nipple
Natural Gas
From Gas Meter
(7" W.C.** to 10.5"
W.C. Pressure)
3" Minimum
External
Regulator with
Vent Pointing
Down
Equipment
Shutoff Valve
13
