Pria Sport
Convertible Car Seat
4358-8203
9.9.21
KEEP INSTRUCTIONS FOR FUTURE USE.
Read all instructions before using this car seat.
WARNING
Failure to follow the warnings on the
labels and in the instruction manual can result in
serious injury or death to your child.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pria Sport and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxi-Cosi Pria Sport

  • Page 1 Pria Sport Convertible Car Seat 4358-8203 9.9.21 KEEP INSTRUCTIONS FOR FUTURE USE. Read all instructions before using this car seat. WARNING Failure to follow the warnings on the labels and in the instruction manual can result in serious injury or death to your child.
  • Page 2 Overview Quick Navigation Welcome to the Maxi-Cosi family and thank you for choosing this car seat, also known as a child restraint! REAR-FACING FORWARD-FACING To help you get started using your child’s new car seat, 14-40 lb (6.4-18 kg) 22-65 lb (10.1-29 kg) here are the 4 main tasks you’ll need to complete:...
  • Page 3: Table Of Contents

    Contents Getting Started Wash & Care of Car Seat Parts Parts of Car Seat ..............Removing Seat Pad Set for Cleaning ........Accessory Use ..............Cleaning Parts of Car Seat & Installing Seat Pad Set ..Choosing Car Seat Mode ...........
  • Page 4: Parts Of Car Seat

    Parts of Car Seat Instruction Manual Storage Adjustable (in pocket in pad) Rear- Headrest Facing Level Line Headrest/ Harness Harness Forward- Adjustment Holders Facing Handle Rear- Belt Path (on back of Facing headrest) Belt Path Shell (car seat) Holder Harness LATCH: Base Release...
  • Page 5: Accessory Use

    Accessory Use For Use in Rear-Facing Mode For Use in Rear-Facing Mode Forward-Facing Mode Forward-Facing Mode Buckle Cover Harness Covers To remove, unbuckle the harness system The harness covers help provide and slide the buckle cover off of the buckle. comfort to your child’s neck.
  • Page 6: Choosing Car Seat Mode

    Choosing Car Seat Mode Measure your child’s weight and height (do not guess) before choosing the car seat’s mode. REAR-FACING MODE 14-40 lb (6.4-18 kg) and 40 in. (101.6 cm) or less Your child’s height, weight, and age determine how the car seat should be placed in the vehicle.
  • Page 7: Preparing Car Seat For Child Fit

    Preparing Car Seat for Child Fit Place Harness Straps Fully Loosen Harness Straps Out of Way Push down on the harness release lever (through the opening in the You can slide the harness straps pad) while pulling out on the harness behind the harness holders as straps as shown.
  • Page 8: Rear-Facing Child Fit

    Rear-Facing Child Fit Forward-Facing Child Fit Head Position Head Position The top of your child’s head must be The tops of your child’s ears must at least 1 in. (2.5 cm) below the top be below the top of the car seat’s of the car seat’s headrest.
  • Page 9: Changing Headrest/Harness Height

    Changing Headrest/ Changing Buckle Position Harness Height Unbuckle Harness Fully Loosen Harness Straps Press in towards the top of the Push down on the harness release Buckle red button and pull out the buckle lever (through the opening in the Tongue tongues.
  • Page 10 Rotate Metal Retainer and Reach Under Car Seat Push It Up Through Buckle Between Base and Shell Slot in Shell Pull the buckle’s metal retainer completely through the seat pad and shell. From Top of Car Seat, Check Buckle Pull Buckle and Buckle Pull up on the buckle to make sure Cover Out of Shell and Pad it is secured.
  • Page 11: Reclining Car Seat

    Reclining Car Seat LATCH: Lower Anchor Use This car seat has 3 positions. For Use in Rear-Facing Mode Forward-Facing Mode Rear-Facing Mode The level-to-ground line on the side of shell must be level with the ground using either Position 3 or 2. LATCH: Lower Anchor Bars Vehicle Seat Bight...
  • Page 12: Vehicle Belts

    Vehicle Belts Adjuster Lower Anchor Connectors Lower Anchor Belt Lower Anchor Lap/Shoulder Belts Storage Attachments Belt Parts To Remove Lower Anchor Belt from Storage Attachment on Car Seat Press the red release button on each connector, then pull the Your vehicle’s features may be considerably different connectors off of the storage attachments.
  • Page 13 Types of Retractors You Must Review Your Vehicle Owner’s Manual Switchable Retractor Your vehicle owner’s manual will let (most vehicles have this type) you know which vehicle belts and seating positions car seats can be This retractor can be switched to a locking mode. installed in.
  • Page 14: Tether Use

    Tether Use Forward-Facing Mode Only Check Latch Plates Latch plates are the part of the seat belt that goes into the buckle. To see if the latch plate locks: 1. Buckle Vehicle Belt Tether Anchors 2. Firmly Tug Lap Portion of Seat Belt While Pulling It Up If the vehicle belt does not slide through the latch plate, it’s locked.
  • Page 15: Rear-Facing Mode

    Rear-Facing Mode Storing Tether Strap 14-40 lb (6.4-18 kg) and 40 in. (101.6 cm) or less When installing in the Rear-Facing Mode or when the car seat is not Strap installed in a vehicle, attach the tether hook to its storage attachment on the back of the car seat as shown.
  • Page 16: Vehicle Belt Install

    Vehicle Belt Install Check Rear-Facing Level Line Before you begin installing the car seat Rear-Facing Level Line must into your vehicle, did you check: be parallel with the ground. Only use Position 2 if necessary to Your child’s weight and height? get the correct recline angle.
  • Page 17 Route Vehicle Belt Tighten Belt Thread the vehicle belt through the Place your hand in the car seat. Rear-Facing Belt Path opening as Firmly push the car seat down and shown. The belt goes: back towards the vehicle seat back •...
  • Page 18 LATCH: Lower Anchor Install Recheck Rear-Facing Before you begin installing the car seat Level Line into your vehicle, did you check: Redo the installation if the car seat is not reclined correctly. Your child’s weight and height? See page 24. Your child’s fi...
  • Page 19 Route Lower Anchor Belt Fully Recline Car Seat Thread the connector without the Pull out on the recline handle and adjuster closest to it through the push the top of the car seat back. Rear-Facing Belt Path opening as Adjuster shown.
  • Page 20 Secure Child in Car Seat ghten Belt To properly secure your child in the Place your hand in the car seat. car seat, see pages 46-48. Firmly push the car seat down and Check your child’s fi t often and make back towards the vehicle seat back any needed adjustments to the car while pulling the free end of the belt...
  • Page 21: Forward-Facing Mode

    Forward-Facing Mode For Children For Children 22-40 lb (10.1-18 kg) and 40-65 lb (18.1-29 kg) and 29-43 in. (73.6-110 cm) 43-49 in. (110.1-125 cm) and at least 1 year old and at least 1 year old You Must Use Position 2 You Must Use Position 1 Lap/Shoulder Lap Belt...
  • Page 22: Vehicle Belt + Tether Install

    Vehicle Belt + Tether Install Before you begin installing the car seat into your vehicle, did you check: If your vehicle seat’s headrest interferes with car seat fi t, check Your child’s weight and height? your vehicle owner’s manual to see See pages 35 and 36.
  • Page 23 Route Vehicle Belt Check Belt Tightness Thread the vehicle belt through the Hold the car seat at the Forward- Forward-Facing Belt Path opening Facing Belt Path with your weaker as shown. The belt goes: hand. • across the car seat; AND Push and pull the car seat from side to side.
  • Page 24 LATCH: Lower Anchor + Tether Install Locate Forward-Facing Before you begin installing the car seat Belt Path into your vehicle, did you check: Your child’s weight and height? See page 35. Your child’s fi t? See page 10. Route Lower Anchor Belt Do you need to make adjustments to the Thread the connector with the harness/headrest height or the buckle position?
  • Page 25 Place Car Seat Forward-Facing Attach Lower Anchor in Back Seat Connectors to Vehicle’s Lower Anchors in Seat Bight The vehicle seat back must be upright. Review your vehicle owner’s manual for LATCH: lower anchor locations and lower anchor belt use. Fasten one connector to one vehicle lower anchor bar.
  • Page 26: Securing Child In Car Seat

    Securing Child in Car Seat Check Belt Tightness Place Child in Car Seat Your child’s bottom and back should Hold the car seat at the Forward- be fl at against the car seat. Facing Belt Path with your weaker hand. Position the harness straps over your child’s shoulders and upper thighs.
  • Page 27 Position Chest Clip Finished! Slide the chest clip up the harness straps and position it at mid-chest Your child is now secured in the (even with armpits) and away from car seat. your child’s neck. Check your child’s fi t often and make any needed adjustments to the car seat as they grow.
  • Page 28: Removing Seat Pad Set For Cleaning

    Removing Seat Pad Set for Cleaning You do not need to remove the harness straps from the splitter Gently Pull Headrest Pad Off plate to remove the pad from the shell. Bottom of Headrest As Shown To remove accessories, see pages 3-4. Remove the headrest pad from the headrest.
  • Page 29: Cleaning Parts Of Car Seat & Installing Seat Pad Set

    Cleaning Parts of Car Seat and Installing Seat Pad Set Cleaning Pad and Accessories Pull Pad Over Outside Edges of Machine wash separately with cold water on a gentle cycle. Make Shell sure the harness covers are closed so the fastening strips are not exposed.
  • Page 30: Installing Harness System

    Installing Harness System Aircraft Information If the harness straps have been removed from the splitter plate, and if the buckle tongues and chest clip have been unthreaded, follow the steps below to rethread them. This restraint is certified for aircraft use. Thread Buckle and Chest Clip The harness strap ends go through the back of the buckle tongues and...
  • Page 31: Replacement And Expiration Of Car Seat

    Replacement and Expiration of Car Seat Do not risk your child’s safety. Child Restraint Use To keep your child as safe as possible, Dorel Juvenile Group strongly Never take your child out of the child restraint while the vehicle recommends replacing the car seat even after a minor crash; is moving.
  • Page 32: Vehicle Seating Position

    Registration and Safety Notices Vehicle Seating Position Please complete the postage-paid registration card that came with your child restraint, and send it to us. Child restraints could be recalled Never place a child rear-facing in a seating for safety reasons. You must register this restraint to be reached in a position with an active frontal air bag.
  • Page 33: Warranty

    Please note: Our product warranty only applies when purchased retail purchaser as follows: This product is warranted against from an authorized Maxi-Cosi retailer. The origin of products not defective materials or workmanship for one year from the date of purchased through these authorized retailers is unknown and could be original purchase.
  • Page 34: Replacement Parts List

    Replacement Parts List Dorel Juvenile Group Information Thank you for choosing this car seat, also known as a child Chest Clip Lower Anchor Belt restraint. The DJG family is committed to creating car seats Buckle Assembly Instructions with the most comfort and convenience available today. Seat Pad Set Locking Clip Remember, parents are a child’s first teachers and...
