Lazer Safe PCSS-F Series Technical Manual page 13

LS-CS-M-023
Channel #
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17-23
Note:
The highlighted fields above are used by the PCSS kernel software directly from the
serial communications so these should not be changed or modified.
Channel #
0-2
3
4
5-14
15
16-23
Note:
The highlighted fields above are used by the PCSS kernel software directly from the
serial communications so these should not be changed or modified.
Channel #
0-31
Channel #
0-31
Original Language Version: 1.02
Description
CNC OK
CNC TDC
CNC Mute
CNC Axis in Position
CNC Moving Up
Spare
CNC 2 Station
CNC Hydraulics On
Spare
Spare
Foot Station 1
Foot Station 2
Foot Station 3
Foot Station 4
CNC Referenced
CNC Decompression
CNC Hydraulic Start
Spare
Table 3-6: CNC Status (CNC_ST)
Description
Spare
Down high speed (down enable option 16 only)
Down low speed (down enable option 16 only)
Spare
Condition changed
Spare
Table 3-7: PCSS Status to the CNC (PCSS_ST)
Description
Spare
Table 3-8: Generic Analog inputs (gA_in)
Description
Spare
Table 3-9: Generic Analog outputs (gA_out)
PCSS-F Additions Technical Manual
Page 3-3
Released: 03/12/2013
