Table 3-5: PCSS operation parameters from the CNC (OperMode)
Note:
The highlighted fields above are used by the PCSS kernel software directly from the
serial communications so these should not be changed or modified.
Page 3-2
Original Language Version: 1.02
Units Description
microns Reference Y1
microns Reference Y2
microns Material thickness
microns Die 01 height
microns Die 02 height
microns Punch 01 height
microns Punch 02 height
microns Tool reference
microns CNC Mute position
microns Upstand height
microns Height of crowning
N/A Reserved
microns Decompression end height
Table 3-3: Analogue inputs received from the CNC (An_in)
Units Description
microns Mute position calculated by PCSS
N/A Condition code from PCSS
Table 3-4: Analogue outputs sent by the PCSS (An_out)
Description
Normal Mode
Tray Mode
Stop at Mute Mode
Reserved
Tool 2
Reserved
Controller (CNC) Not Referenced
Reserved
Robot Mode
Mode 2 foot - 2 foot
Mode 1 foot – 1 foot
Mode 2 hand – 1 foot
Mode 2 hand – 2 hand
Mode 4 hand – 2 foot
Mode 4 hand – 4 hand
Power Up Parameters
Reserved
