1 Notes on this manual
1.1 Validity
This manual will provide detailed product information and installation instructions for
users of model TL3-X series photovoltaic inverter of Shenzhen Growatt new energy Co.,
Ltd. (hereinafter referred to as Growatt new energy). Please read this manual carefully
before using this product. Growatt new energy will not inform users of any changes to
this manual.
MOD 3000TL3-X
MOD 4000TL3-X
MOD 5000TL3-X
MOD 6000TL3-X
MOD 7000TL3-X
MOD 7000TL3-X-AU
MOD 8000TL3-X
MOD 8000TL3-X-AU
MOD 9000TL3-X
MOD 9000TL3-X-AU
MOD 10KTL3-X
MOD 10KTL3-X-AU
MOD 11KTL3-X
MOD 11KTL3-X-AU
MOD 12KTL3-X
MOD 13KTL3-X
MOD 15KTL3-X
1.2 Applicable personnel
The inverter must be installed by professional electricians who are certified by relevant
departments. By reading this manual in detail, the installer can install the MOD TL3-X
series inverter correctly and quickly, and can carry out troubleshooting and
communication system construction.
If there are any problems during the installation process, the installer can log on to
www.growatt.com to leave a message on the website or call our 24-hour service
phone: +86 755 2747 1942 .
1.3 Symbols in this document
1.3.1 Symbols in this document
Warnings indicate hazards to equipment or personnel. It draws your attention to a certain
procedure or practice. If the procedure or practice is not properly implemented or
followed, it may cause damage or destruction of part or all of the Growatt device and/or
other equipment connected to the Growatt device, or cause personal injury.
Symbol
DANGER indicates a hazardous situation which, if not avoided, will
result in death or serious injury.
DANGER
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
WARNING
Description
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
CAUTION
NOTICE is used to address practices not related to personal injury.
NOTICE
Information that you must read and know to ensure optimal
operation of the system.
Information
1.3.2 Markings on this product
Symbol
Danger: Electricity!
Danger:Flame!
Danger:Hot surface!
Operation after 5 minutes
Point of connection for grounding protection
Direct Current (DC)
Alternating Current (AC)
Read the manual
CE mark.
The inverter complies with the requirements of the applicable CE
guidelines.
The inverter must not be disposed of with the household waste.
Explanation
