Summary of Contents for Growatt 2500MTL

  • Page 1 Growatt 2500MTL Growatt 3000MTL Installation & Operation Manual GROWATT NEW ENERGY TECHNOLOGY Co.,LTD No.12 Building, Xicheng Industrial Zone, Bao’an District, Shenzhen, P. R.China + 86 755 2747 1900 + 86 755 2749 1460 service@ginverter.com www.ginverter.com GR - UM - 009 - 04...
  • Page 2 2.1 Unpacking and Inspection 2.2 Information of Label Mounting 3.1 Selecting Mounting Location 3.2 Dimensions and Required Clearances 3.3 Mounting the Bracket 3.4 Mounting Growatt MTL Electrical Connections 4.1 Wiring AC Output 4.2 Wiring DC Input Country Selecting and Commissioning 5.1 Country Selecting...
  • Page 3 7.2 LCD control 7.3 Parameters Setting With this installation guide, users are able to install and operate the Growatt MTL inverters easily. This manual does not cover any details concerning about equipments connected to the Growatt MTL. Store this manual where accessible at all times.
  • Page 4 Growatt New Energy for technical support before installation. 1.4 Safety Growatt MTL is designed for global consumers, and is in accordance with most of the safety standards of various countries and regions. Fig 1.2...
  • Page 5 CAUTION! Possible damage to the PV modules as a result of Identification of String Failure! The Growatt MTL Inverter is equipped with a system which recognizes total failure of individual strings or part-strings. Notes : Operation and installation is required to be in compliance with the local laws and regulation.
  • Page 6: Information Of Label

    2.1 Unpacking and Inspection The inverter type/model (Model Name); The certificates and approvals (Certificate Number and Logos at the bottom of the Before opening the packing box of Growatt MTL, please note that whether there are label); any visible external damages.
  • Page 7 The Ingress Protection rate (IP level) is IP65 which means Growatt Do not install Growatt MTL in living area, the noise caused by MTL can be installed both indoors and outdoors. inverter might affect on daily life.
  • Page 8: Mounting The Bracket

    3.3 Mounting the Bracket 3.4 Mounting Growatt MTL To install Growatt MTL on the wall, installers should mount the bracket to the wall After the bracket is firmly mounted on the wall, then install Growatt MTL onto the firmly as the first step.
  • Page 9: Electrical Connections

    AWG no. Model Area(mm²) _(mm) Connect the positive and negative terminal from the PV panels to positive and negative terminal on the PV inverter. The maximum string currents are varying 2500MTL _2.05 3.332 from different inverter types; 3000MTL _2.05 3.332 Table 4.1...
  • Page 10 Cable requirements: Country/Regulation Name options Model Area(mm²) AWG no. _(mm) VDE0126-1-1 // 0 Germany // 1 2500MTL _2.05 3.332 UK_G83 // 2 3000MTL _2.05 3.332 Italy // 3 France // 4 Denmark // 5 Table 4.3 Belgium // 6 Notes: Under no circumstances could the total circuit current exceed the Max.
  • Page 11: Operation Modes

    When the selection is successful, the inverter will reboot automatically. enter the next interface. Here we select Italy as an example, as Fig 5-1-3. Note: If you have selected and confirmed an unwanted country neglectful, please contact Growatt for specific software to clear and reset again. Fig 5-1-3 5.2 Commissioning...
  • Page 12: Display And Messages

    Growatt MTL automatically stop running during periods of little or no sunlight. In Reconnect in xxS System checking shutdown mode Growatt MTL won’t take any power from the grid or panels, and LCD and LED turns off. Normal Connect OK...
  • Page 13 CYCLE DISPLAY DISPLAY TIME/S REMARK STATUS DISPLAY CONTENT REMARK Fault Error: xxx System fault Total generated energy since installation.For Auto Test Auto Testing Protecting function accurate energy to get the FIT payment, please refer to your meter Programming Programming Firmware update PV input power Table 7.1 Notes:...
  • Page 14: Parameters Setting

    Users can use sound control function to change the display language and luminance of the display, enable auto-test function and choose utility model. ShineNet is a monitoring software applied to monitor Growatt inverters via RS232 port or Bluetooth module. With the special designed functions and friendly compact UI, it can comprehensively meet users’...
  • Page 15 Features: Monitor and record current data and of inverters. Record historical data. Monitor and record event information of inverter. Connect computer and inverter via RS232 and RS485 port (wire connection) or Bluetooth module (wireless connection). Remote access available for local area network. Fig 8.2 Notes: Users are able to monitor the inverter after the setting of software.
  • Page 16: Troubleshooting

    A multi-functional and high-performance communication data logger; Collects data and uploads information over the internet in near real-time Keep user informed of the system’s status at any time. to Growatt Shine Server platform. Massive storage with flexible parameters setting, system information management, error prompt and record.
  • Page 17: System Fault

    Utility grid frequency 1.Check grid frequency. out of permissible 2.If the error message is displayed You may be advised to contact Growatt in some situation, please provide the following information. range. despite the grid frequency being within the tolerable range, Information concerning the inverter: contact Growatt.
  • Page 18: Specifications

    Number of MPP trackers different. The reason replacement, check utility grid. /strings per MPP tracker can be utility grid voltage If you require help, contact Growatt. Max. input current / 2*10A/10A 2*10A/10A 3.If error message still exists, or frequency change per string contact Growatt.
  • Page 19: Growatt Factory Warranty

    -30 °C ... +45 °C -30 °C ... +45 °C temperature range Growatt 20000UE. For the above named products, you receive a Growatt factory warranty valid for 5 Noise emission (typical) ≤25 dB(A) ≤25 dB(A) years from the date of installation and no more than five and a half years from the delivery date from Growatt New Energy Co., Ltd.
  • Page 20 Modules information taking into account the significance of the defect, and after consideration of alternative workaround possibilities that Growatt Communication method customers could revert to without significant inconvenience.
