Manual
Off-line Filter Unit
FNA1 008 / FNA1 016
www.argo-hytos.com
Subject to change · 0324· EN
Safety and operating instructions
Read safety and operating instructions before use.
Note:
The indicated data only serve to describe the product.
Specifications regarding the use of this product are only examples and suggestions.
Catalog specifications are no guaranteed features.
The information given does not release the user from his / her own assessments and inspection.
Our products are subject to a process of natural wear and aging.
© All rights are reserved by ARGO-HYTOS, even in the event of industrial property rights.
Any right of disposal such as copying and distribution rights shall remain with us.
The picture on the title page shows a configuration example.
The delivered product may thus differ from the illustration.
Page 1
Advertisement
Table of Contents
Related Manuals for Argo-Hytos FNA1 008
Summary of Contents for Argo-Hytos FNA1 008
- Page 1 Our products are subject to a process of natural wear and aging. © All rights are reserved by ARGO-HYTOS, even in the event of industrial property rights. Any right of disposal such as copying and distribution rights shall remain with us.
-
Page 2: Table Of Contents
Off-line Filter Unit FNA1 008 / FNA1 016 Contents Contents .................................... 2 About this documentation ............................... 4 Applicability of this documentation ............................4 Required and supplementary documentation ........................4 Presentation of information ..............................4 Safety instructions ................................6 About this chapter ................................6 Intended use .................................. - Page 3 Annex ....................................28 15.1 Hydraulic circuit diagrams ..............................28 15.2 Connection diagrams ................................ 29 15.3 Spare parts lists ................................. 30 15.4 Installation declaration ............................... 32 Page 3 www.argo-hytos.com Subject to change · 0324· EN...
-
Page 4: About This Documentation
This documentation is applicable for the following product series: › Off-line Filter Unit FNA1 008 / FNA1 016 This documentation is written for technicians, operators, service engineers and system operators. This document contains important information for safe and appropriate assembly, transport, activation, operation, usage, servicing, dismantling and simple troubleshooting. - Page 5 In this documentation the following terms are used: Term Meaning FNA1 Off-line Filter Unit Table 4: Terms 1.3.4 Abbreviations In this documentation the following abbreviations are used: Term Meaning Table 5: Abbreviations Page 5 www.argo-hytos.com Subject to change · 0324· EN...
-
Page 6: Safety Instructions
Therefore only use this product in safety-related applications if this use is explicitly specified and permitted in the product documentation, e.g. in explosion protection areas or in safety-related parts of a control system (functional safety). ARGO-HYTOS assumes no liability for damages resulting from improper use. The risks associated with improper use are solely with the user. -
Page 7: General Safety Instructions
› Observe all instructions on the product. › People who assemble, operate, disassemble or maintain ARGO-HYTOS products may not do so under the influence of alcohol, other drugs or medications that affect the responsiveness. › Only use manufacturer-approved accessories and spare parts, in order to prevent personal danger due to unsuitable spare parts. -
Page 8: General Instructions
Danger due to improper handling Property damage › The off-line filter unit FNA1 008 / FNA1 016 may only be used in accordance with Section 2.2, “Intended use”. Leakage or spillage of hydraulic fluid Environmental pollution and ground water contamination. -
Page 9: Scope Of Delivery
Scope of delivery The package includes: › 1 Off-line Filter Unit FNA1 008 / FNA1 016 › 1 Operating manual › Mounting kit (rubber buffers, washers, nuts) Page 9 www.argo-hytos.com Subject to change · 0324· EN... -
Page 10: About This Product
About this product The off-line filter unit “FNA1 008 / FNA1 016“ is a filter system for filtering hydraulic fluids in the bypass flow. Type plate NOTE Type plates are documents; they must not be modified or removed. › Damaged or lost type plates must be replaced with exact copies of the original. -
Page 11: Component Overview
2 Filter housing 6 Hydraulic pump 3 Filter element 7 Electric motor 4 Connection for clogging indicator (connection type: port M12x1.5 or flange depending on the version of the unit Page 11 www.argo-hytos.com Subject to change · 0324· EN... -
Page 12: Transport And Storage
Treat all bare parts with preservatives. 6.2.2 Storage › Do not store the unit near flammable liquids or gases. › Do not store in the rain or in damp and wet environment. Page 12 www.argo-hytos.com Subject to change · 0324· EN... -
Page 13: Installation
A missing suction strainer can lead to destruction of the pump. In this case, the manufacturer assumes no liability. › With installation of the off-line filter units, a clogging indicator must be used. › Without a clogging indicator, element contamination is not detectable. Page 13 www.argo-hytos.com Subject to change · 0324· EN... -
Page 14: Mains Connection
Switch the unit off or disconnect it from the mains to avoid consequential damage to people and the environment when the voltage returns, e.g. due to overflowing oil or danger of slipping due to leaking oil. Page 14 www.argo-hytos.com Subject to change · 0324· EN... -
Page 15: Installation Recommendations
When installing the off-line filter units, a contamination indicator must be used. › Without a clogging indicator, element clogging cannot be detected. Device type FNA1 008 / FNA1 016 Installation position Vertical Fixing Mounting only by using the supplied mounting kit (M Clearance filter element min. -
Page 16: Operation Of The Off-Line Filter Unit
› Keep an adequate filtration time - recommended guideline values: 60 minutes per 100 l / 26.4 gal tank capactiy with FNA1 008 devices 30 minutes per 100 l / 26.4 gal tank capacity with FNA1 016 devices Page 16 www.argo-hytos.com... -
Page 17: Technical Data
600 µm (optional) Electric drives see page 18 FNA1 008 / 23050 1~ AC motor with operating capacitor, 220-240 V, 50/60 Hz, 0.25 kW/0.30 kW; n = 1500/1800 min –1 FNA1 008 / 40050 3~ three-phase motor, 400/460 V, 50/60 Hz, 0.25 kW/0.30 kW; n = 1500/1800 min –1... - Page 18 -12 UN-2B 3 or 4 Out: -16 UN-2B Filter element Code Fineness (β=200) Dirt-holding capacity according to Filter ISO 16889 / water capacity element FNA1 008 FNA1 016 EXAPOR MAX 2 3 µm 490 g 280 g V7.1220-113 V003 ® EXAPOR MAX 2 5 µm...
-
Page 19: Operating Conditions
0 °C to 50 °C / 32 °F to 122 °F Permissible viscosity range Type of unit Continuous operation Continuous operation Short-term operation min. max. max. FNA1 008 15 mm 250 mm 400 mm FNA1 016 15 mm 250 mm 400 mm Permissible suction heights max. -
Page 20: Maintenance
If dirt enters the pump during maintenance work, optimal functioning of the device is no longer guaranteed. In this case, the manufacturer assumes no liability! NOTE When performing any work: › Wear protective gloves, safety shoes and safety goggles! Page 20 www.argo-hytos.com Subject to change · 0324· EN... -
Page 21: Disassembly Of The Pump / Motor
Remove the pump plate (5) together with the wheel set (5.1) from the motor (9) and lift them upwards. Detach the motor (9) from the brackets. Dispose of old parts in an environmentally compatible way. Fig. 5: Exploded view of the off-line filter unit Page 21 www.argo-hytos.com Subject to change · 0324· EN... -
Page 22: Installation Of The Pump / Motor
0.3 l oil. If the electrical supply has been removed from the motor, connect it in accordance with the electrical circuit diagrams. Page 22 www.argo-hytos.com Subject to change · 0324· EN... -
Page 23: Changing The Filter Element
Release the filter element from the cover by moving it as shown in Fig. 6. Dispose of the filter element in accordance with environmental regulations, waste code: OIL FILTER 16 01 07 Fig. 6: Releasing the fixture at the cover / filter element Page 23 www.argo-hytos.com Subject to change · 0324· EN... - Page 24 Fig. 7: Attaching the cover to the filter element NOTE › Oil that has accidently drained onto components of the off-line filter unit when changing the filter element, could be considered as leakage oil. Page 24 www.argo-hytos.com Subject to change · 0324· EN...
- Page 25 Attach the suction strainer (3) to the suction hose (2) according to Fig. 8 and secure it with the hose clamp (1). Fig. 8: Suction strainer FA 016.0303 Position Designation Order number Hose clamp DIN 03017 Suction strainer FA 016.0301S7 Table 10: Spare parts suction strainer FA 016.0301S7 Page 25 www.argo-hytos.com Subject to change · 0324· EN...
-
Page 26: Faultfinding / Troubleshooting
Clean off-line filter unit Oil is running out of the terminal box element change › › Screw connection is leaking Check screw connections, tighten / seal them if necessary Table 11: Fault table Page 26 www.argo-hytos.com Subject to change · 0324· EN... -
Page 27: Decommissioning / Disposal
Uninstallation of electrical components may only be carried out by qualified electricians. WARNING › Uninstallation of the filter and pumping-over unit may only be carried out by qualified electricians. › Risk of injury of any kind. Page 27 www.argo-hytos.com Subject to change · 0324· EN... -
Page 28: Annex
Type 1 (code O) Type 2 (code E) Type 3 (code EO) Type 4 (code X) Type 5 (code OD) Type 6 (code ED) Type 7 (code EOD) Type 8 (code XD) Page 28 www.argo-hytos.com Subject to change · 0324· EN... -
Page 29: Connection Diagrams
Electrical connection of the off-line filter units may only be carried out by qualified electricians. Connections Connections Grounding Grounding Delta connection Star connection Type1 3~ delta connection Type 1 3~ star connection Connections 1~ Alternating current Type 2 1~ alternating current Page 29 www.argo-hytos.com Subject to change · 0324· EN... -
Page 30: Spare Parts Lists
15.3 Spare parts list 15.3.1 Spare parts drawing Fig. 9: Spare parts drawing FNA1 008/016 Page 30 www.argo-hytos.com Subject to change · 0324· EN... - Page 31 FNA1 016...23050 43650500 FNA1 016...40050 33591600 FNA1 016...11050 Mounting set 34496400 All types Table 12: Spare part list Note: For other spare parts not listed in this manual please contact info.pl@argo-hytos.com Page 31 www.argo-hytos.com Subject to change · 0324· EN...
-
Page 32: Installation Declaration
Władysława Grabskiego 27 32-640 Zator, Poland, declare on our sole responsibility that the all products of product range Off-line Filter Unit FNA1 008; FNA1 016 to which this declaration refers, conforms to the following standards and normative documents: Directive 2006/42/EC (Machinery Directive) - Page 33 ARGO-HYTOS Hong Kong Ltd. info.hk@argo-hytos.com India ARGO-HYTOS PVT. LTD. info.in@argo-hytos.com Italy ARGO-HYTOS S.r.l. info.it@argo-hytos.com Poland ARGO-HYTOS Polska spz o.o. info.pl@argo-hytos.com Sweden ARGO-HYTOS Nordic AB info.se@argo-hytos.com Turkey ARGO-HYTOS Hidrolik Ekip. San. ve Tic. Ltd. Şti. info.tr@argo-hytos.com ARGO-HYTOS Inc. info.us@argo-hytos.com 03.2024 · EN...
