Manual
Compact Filter Pack
CFP 03
www.argo-hytos.com
Subject to change · 40719700 · 1217 · EN
Safety and operating instructions
Read safety and operating instructions before use.
Note:
The indicated data only serve to describe the product.
Specifi cations regarding the use of this product are only examples and suggestions.
Catalog specifi cations are no guaranteed features.
The information given does not release the user from his / her own assessments and inspection.
Our products are subject to a process of natural wear and aging.
© All rights are reserved by ARGO-HYTOS GMBH, even in the case of industrial property rights.
Any right of disposal such as copying and distribution rights shall remain with us.
The picture on the title page shows a confi guration example.
The delivered product may thus differ from the illustration.
Page 1
Advertisement
Table of Contents
Related Manuals for Argo-Hytos CFP 03
Summary of Contents for Argo-Hytos CFP 03
- Page 1 Manual Compact Filter Pack CFP 03 Safety and operating instructions Read safety and operating instructions before use. Note: The indicated data only serve to describe the product. Specifi cations regarding the use of this product are only examples and suggestions.
-
Page 2: Table Of Contents
Compact Filter Pack CFP 03 Contents Contents ..................................2 In this documentation ..............................4 Applicability of this documentation...........................4 Required and additional documentation .......................... 4 Presentation of information ............................. 4 1.3.1 Safety instructions ................................4 1.3.2 Symbols................................... 5 1.3.3 Terms ....................................5 1.3.4... - Page 3 Disposal ..................................22 Extension..................................23 14.1 Optional accessories ..............................23 14.1.1 Suction-return set ................................. 23 14.1.2 Additional adapter................................. 23 Troubleshooting................................24 15.1 How to proceed ................................24 15.2 Fault table ..................................25 Technical data ................................26 16.1 Technical data................................26 16.2 Device dimensions .................................
-
Page 4: In This Documentation
This documentation is applicable for the following product: › Compact Filter Unit CFP 03 This documentation is written for technicians, operators, service engineers and system operators. This document contains important information for safe and appropriate assembly, transport, activation, operation, usage, servicing, dismantling and simple troubleshooting. -
Page 5: Symbols
1.3.2 Symbols The following symbols indicate notes which are not safety-relevant but increase the intelligibility of the documentation. Symbol Meaning If this information is not observed, the product cannot optimally be used or operated > Singular, independent action step / instruction Numbered instruction The numbers indicate that the action steps follow one another This symbol indicates danger to equipment, material and environment... -
Page 6: Safety Instructions
2. Safety instructions In this chapter This product was manufactured according to the generally recognized standards of engineering. Nevertheless, there is a danger of injury or damage if you do not observe this chapter and the safety instructions in this documentation. ›... -
Page 7: General Safety Instructions
General safety instructions › Observe the valid regulations for accident prevention and environmental protection. › Observe the safety regulations and requirements of the country in which the product is used / applied. › Only use ARGO-HYTOS products that are in technically perfect condition. ›... -
Page 8: General Instructions
3. General instructions For prevention of material damage and product damage CAUTION CAUTION Danger due to improper handling Property damage › The fi lter unit may only be used in accordance with Section 2.2, “Intended use”. Leakage or spillage of hydraulic fl uid Environmental pollution and ground water contamination. -
Page 9: Scope Of Delivery
4. Scope of delivery Scope of components The unit is supplied with a set of hydraulic hoses. The suction hose DN8 is installed in the suction port of the pump. The oil sucked from the system / barrel is pumped by the pump into the main fi lter and then, after being fi ltered, it is transferred to a DN6,5 discharge hose, connected to the fi lter output. -
Page 10: About This Product
Pump with relief pressure valve Suction filter Suction hose Pressure hose Plug with power cord Suction hose plug Pressure hose plug Fig. 3: CFP 03 component overview 1 Page 10 www.argo-hytos.com Subject to change · 40719700 · 1217 · EN... -
Page 11: Identification Of The Product
Fig. 4: CFP 03 component overview 2 + 3 Identification of the product The unit is provided with its own permanent and readable nameplate, located in a prominent position and containing the basic data of the unit. Fig. 5: Nameplate NOTE Nameplates are documents which must not be changed or removed. -
Page 12: Transport And Storage
6. Transport and storage Transport CAUTION CAUTION Falling unit through incorrect transport Injury and property damage › Wear safety shoes when transporting the fi lter unit. Fig. 6: Transport A plastic holder is attached to the unit’s frame to make its transport easier. Due to the fact that the weight does not exceed 10 kg, the device can be carried manually. -
Page 13: Assembly
7. Assembly WARNING Faulty power supply Risk of death and injury › Always consider the country-specifi c regulations. Let - prior to commissioning - an electrician check whether: › the mains voltage matches with the voltage specifi ed on the type plate of the motor, ›... -
Page 14: Commissioning
8. Commissioning Before commissioning › Ensure cleanliness during installation in order to prevent debris such as welding beads or metal shavings from entering the hydraulic lines and causing wear and malfunctions in the product. › Make sure the connections, hydraulic lines and fittings are free of dirt and chips ›... -
Page 15: Operation
9. Operation CAUTION CAUTION Exposure to spilled oil Injury / risk of slipping › If oil leaks, the oil-covered area must be shut of immediately and covered with an oil binding medium (risk of slipping). Static charge Sparking › There is a risk of static charge when using poorly conducting hydraulic or lubricating oils. In this case, please consult the manufacturer. -
Page 16: Filtering Fluids In The Bypass Flow
Filtering fluids in the bypass flow 1. Connect the filter unit to a power source. 2. Place the suction strainer in the tank of the machinery or equipment (e.g. hydraulic tank). 3. Place the discharge pipe in the tank of the machinery or equipment (e.g. hydraulic tank). 4. -
Page 17: Maintenance / Repair
10. Maintenance / repair DANGER DANGER Danger to life Risk of electric shock › During repair work, turn off the unit and pull the mains plug. CAUTION CAUTION Risks related to chemical reactions Risk of injury › Chemical substances in the immediate vicinity of the fi lter unit may react and lead to destruction of the device and to injuries of persons who are in the immediate vicinity of the device ›... -
Page 18: Maintenance
10.1 Maintenance 10.2 Maintenance overview Except from the fi lter element and the suction strainer, the fi lter unit is maintenance-free. Maintenance work Order No. Maintenance interval Checking / changing the fi lter element V3.0510-53 (5 µm) Once the clogging indicator changes to the V3.0510-56 (10 µm) red range at a permissible viscosity V3.0510-58 (16 µm) -
Page 19: Replacing The Filter Element
10.3. Replacing the fi lter element Turn the fi lter unit off at the ON/OFF switch (circuit breaker) and pull the mains plug. CAUTION CAUTION Risk of burns Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during operation. -
Page 20: Decommissioning
11. Decommissioning DANGER DANGER Danger to life Risk of electric shock › Before uninstalling, pull the mains plug. Uninstalling may only be carried out by qualifi ed electricians. Risk of injury Risk of injury by incorrect handling › Uninstalling may only be carried out by instructed persons. The fi nal decommissioning and disposal requires complete uninstallation of the total energy supply, the mechanical components and the disposal of the hydraulic media remaining in the device. -
Page 21: Disassembly
12. Disassembly The filter unit is a device which does not have to be dismantled. Page 21 www.argo-hytos.com Subject to change · 40719700 · 1217 · EN... -
Page 22: Disposal
13. Disposal › Careless disposal of the filter unit CFP and the hydraulic fluid can lead to environmental pollution. › Therefore, dispose of the filter unit and the hydraulic fluid in accordance with the national regulations of your country. › Dispose of hydraulic fluid residues according to the applicable safety data sheets for these hydraulic fluids. -
Page 23: Extension
14. Extension 14.1 Optional accessories 14.1.1 Suction-return set Order no. CFP-A-09/05 For off-line fi ltration in systems with steel tank with only one available port. Set of connection fittings G 1/2" and M22x1.5 delivered with adapter Return pipe Suction pipe ~ 90 (~3.54 inch) ~ 63 (~2.48 inch) Fig. -
Page 24: Troubleshooting
15. Troubleshooting 15.1 How to proceed › Get an overview on the function of the product in connection with the overall system. › Try to find out whether the product had provided the required function in the overall system before the error occurred. ›... -
Page 25: Fault Table
15.2 Fault table Problem / fault Possible cause Elimination › › Electric motor does not Electrical cable or mains plug Have the cable replaced by a skilled electrician turn on during defective commissioning › › Supply voltage missing Establish the power supply or activate the electric fuse ›... -
Page 26: Technical Data
Hose DN 8, length 2.2 m Pressure side Hose DN 8, length 2.0 m Electric drive 1 ~230 V Motor; 50 Hz; 03-13, CFP 03-13, CFP 03-18 0.06 kW, n=1,450 min Weight approx. 9 Sound power level db(A) max. 65 (under operating conditions permitted for continuous... -
Page 27: Operating Conditions
16.3 Operating conditions Permitted temperature range Hydraulic fl uid °C 0 ... 60 (note viscosity range) Ambient temperature °C 0 ... 50 CAUTION CAUTION Risk of burns Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during operation. -
Page 28: Appendix
Władysława Grabskiego 27 32-640 Zator, Poland, declare on our sole responsibility that the products in the model series Filter unit CFP 03 to which this declaration pertains are in conformity with the following directives: Directive 2006/42/EC (Machinery Directive) Directive 2004/108/EC (EMC Directive) -
Page 29: Spare Parts List
Hydraulic pump 40119400 Filter cap D 043.2202 Filter cap sealing N 031.0562 Filter element V3.0510-53 5 µm , model CFP 03-13 Filter element V3.0510-56 10 µm, model CFP 03-16 Filter element V3.0510-58 16 µm, model CFP 03-18 Suction strainer set... - Page 30 www.argo-hytos.com International ARGO-HYTOS worldwide Benelux ARGO-HYTOS B. V. info.benelux@argo-hytos.com Brazil ARGO-HYTOS AT Fluid Systems Ltda. info.br@argo-hytos.com China ARGO-HYTOS Fluid Power Systems (Yangzhou) Co., Ltd. info.cn@argo-hytos.com ARGO-HYTOS Fluid Power Systems (Beijing) Co., Ltd. info.cn@argo-hytos.com ARGO-HYTOS Hong Kong Ltd. info.hk@argo-hytos.com Czech Republic ARGO-HYTOS s.r.o info.cz@ argo-hytos.com ARGO-HYTOS Protech s.r.o...
