Operating Manual
Filter Unit
FA 008
www.argo-hytos.com
Subject to change · 33143400 · 05.2016 · EN
Safety and operating instructions
Read safety and operating instructions before use.
Note:
The indicated data only serve to describe the product.
Information regarding the use of this product are only examples and suggestions.
Catalog specifications are no guaranteed features.
The information given does not release the user from his / her own assessments and inspection.
Our products are subject to a process of natural wear and aging.
© All rights are reserved by ARGO-HYTOS GMBH, even in the event of industrial property rights.
Any right of disposal such as copying and distribution rights shall remain with us.
The picture on the title page shows a configuration example.
The delivered product may thus differ from the illustration.
Page 1
Advertisement
Table of Contents
Related Manuals for Argo-Hytos FA 008
Summary of Contents for Argo-Hytos FA 008
- Page 1 Our products are subject to a process of natural wear and aging. © All rights are reserved by ARGO-HYTOS GMBH, even in the event of industrial property rights. Any right of disposal such as copying and distribution rights shall remain with us.
-
Page 2: Table Of Contents
Filter Unit FA 008 Contents Contents ..................................2 About this documentation ............................4 Applicability of this documentation ..........................4 Required and supplementary documentation ........................4 Presentation of information ............................. 4 1.3.1 Safety instructions ................................4 1.3.2 Symbols................................... 5 1.3.3 Terms ....................................5 1.3.4... - Page 3 Technical data................................29 16.3 Operating conditions ..............................30 16.4 Hydraulic circuit diagrams .............................. 30 Appendix ..................................31 17.1. Declaration of Conformity ............................. 31 17.2 Spare parts list ................................32 Page 3 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN...
-
Page 4: About This Documentation
This documentation is applicable for the following product: › Filter Unit FA 008 This documentation is written for technicians, operators, service engineers and system operators. This document contains important information for safe and appropriate assembly, transport, activation, operation, usage, servicing, dismantling and simple troubleshooting. -
Page 5: Symbols
In this documentation the following terms are used: Term Meaning Table 4: Terms 1.3.4 Abbreviations In this documentation the following abbreviations are used: Term Meaning Filter Unit Table 5: Abbreviations Page 5 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 6: Safety Instructions
Therefore only use this product in safety-related applications if this use is explicitly specified and permitted in the product documen- tation, e.g. in explosion protection areas or in safety-related parts of a control system (functional safety). ARGO-HYTOS GMBH assumes no liability for damages resulting from improper use. The risks associated with improper use are solely with the user. -
Page 7: General Safety Instructions
› Observe all instructions on the product. › People who assemble, operate, disassemble or maintain ARGO-HYTOS products may not do so under the influence of alcohol, other drugs or medications that affect the responsiveness. › Only use manufacturer-approved accessories and spare parts, in order to prevent personal danger due to unsuitable spare parts. -
Page 8: General Instructions
Do not use aggressive cleaning agents for cleaning. Clean the product with a suitable cleaning fluid. Do not use a high pressure cleaner. Do not use compressed air to clean function interfaces such as seal areas. Page 8 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 9: Scope Of Delivery
4. Scope of delivery The package includes: › 1 Filter Unit FA 008 › 1 Operating manual Page 9 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 10: About This Product
The operating temperature is in the range of 0° C to 65° C. Device description The filter unit FA 008 consists of a support frame in which a filter pump unit is integrated. This consists of an electrically operated filter pump with exchangeable filter element and a gauge as maintenance indicator. -
Page 11: Identification Of The Product
Identification of the product Fig. 2: Nameplate Max. pressure Year of manufacture Nominal volume flow Type designation Filter fineness Address Page 11 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 12: Transport And Storage
The ambient temperature during storage of the filter unit FA 008 should be between + 5 °C and + 30 °C at a humidity of 80 %. Before storage over a period of more than 6 months, the unit should be filled with oil in order to preserve it against corrosion. -
Page 13: Assembly
Specifically, proceed with the following steps: › Connect the 230 V voltage plug to the local power supply. Page 13 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 14: Commissioning
Check the filter unit for leaks. In case of power failure In order to prevent unintentional starting of the unit, always switch off and unplug the unit. Page 14 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 15: Operation
Check the filling level at the machine or system and turn off the filter unit at the circuit breaker, once the desired filling quantity has been reached. Re-attach the suction strainer and the discharge pipe at the appropriate brackets at the filter unit. Page 15 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 16: Filtering Liquids In The Bypass Flow
Reaching the maximum cleaning performance In order to prevent a short circuit of the oil flow, the distance between the suction and pressure connection should be kept as large as possible. Page 16 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 17: Maintenance / Repair
The function of the filter unit is no longer guaranteed. During repair work, all parts coming in contact with the hydraulic medium, must be kept free of dirt and chips. Page 17 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 18: Maintenance
Clean the suction strainer (3) using benzine or diesel fuel. NOTE In case of damage, replace the suction strainer (3) (Order No. FA 008.0110). Push the suction hose (2) - as shown above - onto the suction strainer (3) Attach the hose clamp (1). -
Page 19: Replacing The Filter Element
Screw in the cover manually until it stops. A gap between cover and filter pipe may remain visible (see Chapter 8.1 "Before commissioning" / Fig. 3) Fig. 8: Installing the filter element Page 19 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 20: Replacing The Pump
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during operation. Allow the filter unit to cool down before touching it. Fig. 9: Replacing the motor and the pump Page 20 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 21: Removing The Pump
Risk of burns Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during operation. Allow the filter unit to cool down before touching it. Page 21 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 22: Removing The Motor
The device can be put into operation. If not oil is sucked during commissioning, open the cover at the filter housing and fill with about 300 ml oil. Page 22 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 23: Decommissioning
The final decommissioning and disposal requires complete uninstallation of the total energy supply, the mechanical components and the disposal of the hydraulic media remaining in the device. With disassembly and disposal, all national safety and environmental regulations must be observed. Page 23 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 24: Disassembly
12. Disassembly The filter unit is a device that does not need to be dismantled. Page 24 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 25: Disposal
13. Disposal Careless disposal of the filter unit FA 008 and the hydraulic fluid can lead to environmental pollution. Therefore, dispose of the filter unit and the hydraulic fluid in accordance with the national regulations of your country. Dispose of hydraulic fluid residues according to the applicable safety data sheets for these hydraulic fluids. -
Page 26: Extension
Optional accessories 14.1.1 Hose extensions On request, ARGO-HYTOS also provides you with hose extensions according to your stipulations. Fig. 10: Option "Suction strainer set" The suction strainer set FA 016.1775 guarantees pump protection, when the existing suction strainer at the suction pipe cannot be used. -
Page 27: Troubleshooting
- Has the product or the device been operated correctly? - How does the fault tend to show? › Get a clear impression about the cause of trouble. Possibly consult the direct operator or machine operator. Page 27 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 28: Fault Table
Clean filter unit › Oil leaking out of filter element change terminal box Screwing leaky Check the screw joints, re-tighten and / or seal them Table 7: Fault table Page 28 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 29: Technical Data
Hose DN 20 with suction strainer, length 1.8 m Pressure side Hose DN 20 with discharge pipe, length 2.0 m Electric drive 1 ~230 V Motor; 50 Hz; FA 008-1180, -1380 und 1680 0,25 kW, n=1.500 min Tare weight approx. 17.0 Sound power level db(A) max. -
Page 30: Operating Conditions
Before use with synthetic fluids please contact the manufacturer. Work position Abitrarily, perferably standing Mains fuse 230 V, 50 Hz, 10 - 16 Amps FA 008 - 1180, -1380, -1680 16.4 Hydraulic circuit diagrams Fig. 12: Hydraulic circuit diagram Suction hose... -
Page 31: Appendix
17. Appendix 17.1 EC-Declaration of Conformity Page 31 www.argo-hytos.com Subject to change · 33143400 · 05.2016 · EN... -
Page 32: Spare Parts List
FA 008.0110 Suction hose FNA 016.0106 Pressure gauge FDG 200-16 Pressure hose FA 008.0107 Filter element V7.1220-06 at FA 008-1680 V7.1220-13 at FA 008-1380 V7.1220-113 at FA 008-1180 Cover complete FNA 008.1250 Table 9: Spare parts list Page 32 www.argo-hytos.com... - Page 33 ARGO-HYTOS worldwide Benelux ARGO-HYTOS B. V. info.benelux@argo-hytos.com Brazil ARGO-HYTOS AT Fluid Systems Ltda. info.br@argo-hytos.com China ARGO-HYTOS Fluid Power Systems (Yangzhou) Co., Ltd. info.cn@argo-hytos.com ARGO-HYTOS Fluid Power Systems (Beijing) Co., Ltd. info.cn@argo-hytos.com ARGO-HYTOS Hong Kong Ltd. info.hk@argo-hytos.com Czech Republic ARGO-HYTOS GMBH info.cz@ argo-hytos.com...
