Manual
Off-line Filter Unit
FNA 040
www.argo-hytos.com
Subject to change · 27897500 · 10.2016 · EN
Safety and operating instructions
Read safety and operating instructions before use.
Note:
The indicated data only serve to describe the product.
Specifications regarding the use of this product are only examples and suggestions.
Catalog specifications are no guaranteed features.
The information given does not release the user from his / her own assessments and inspection.
Our products are subject to a process of natural wear and aging.
© All rights are reserved by ARGO-HYTOS GMBH, even in the event of industrial property rights.
Any right of disposal such as copying and distribution rights shall remain with us.
The picture on the title page shows a configuration example.
The delivered product may thus differ from the illustration.
Page 1
Advertisement
Table of Contents
Related Manuals for Argo-Hytos FNA 040
Summary of Contents for Argo-Hytos FNA 040
- Page 1 Our products are subject to a process of natural wear and aging. © All rights are reserved by ARGO-HYTOS GMBH, even in the event of industrial property rights. Any right of disposal such as copying and distribution rights shall remain with us.
-
Page 2: Table Of Contents
Off-line Filter Unit FNA 040 Contents Contents .................................... 3 About this documentation ............................... 4 Applicability of this documentation ............................4 Required and supplementary documentation ........................4 Presentation of information ..............................4 Safety instructions ................................6 About this chapter ................................6 Intended use .................................. -
Page 3: Contents
Operating conditions ................................. 25 15.4 Hydraulic circuit diagram ..............................25 15.5 Connection diagram ................................26 Appendix ..................................27 16.1 Declaration of conformity ..............................27 16.2 Spare parts list ................................... 28 Page 3 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 4: About This Documentation
This documentation is applicable for the following product: › Off-line Filter Unit FNA 040 This documentation is written for technicians, operators, service engineers and system operators. This document contains important information for safe and appropriate assembly, transport, activation, operation, usage, servicing, dismantling and simple troubleshooting. - Page 5 In this documentation the following terms are used: Term Meaning Table 4: Terms 1.3.4 Abbreviations In this documentation the following abbreviations are used: Term Meaning Off-line Filter Unit Table 5: Abbreviations Page 5 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN...
-
Page 6: Safety Instructions
Therefore only use this product in safety-related applications if this use is explicitly specified and permitted in the product documentation, e.g. in explosion protection areas or in safety-related parts of a control system (functional safety). ARGO-HYTOS GMBH assumes no liability for damages resulting from improper use. The risks associated with improper use are solely with the user. -
Page 7: General Safety Instructions
› Observe all instructions on the product. › People who assemble, operate, disassemble or maintain ARGO-HYTOS products may not do so under the influence of alcohol, other drugs or medications that affect the responsiveness. › Only use manufacturer-approved accessories and spare parts, in order to prevent personal danger due to unsuitable spare parts. -
Page 8: General Instructions
Do not use aggressive cleaning agents for cleaning. Clean the product with a suitable cleaning fluid. › Do not use a high pressure cleaner. › Do not use compressed air to clean function interfaces such as seal areas. Page 8 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 9: Scope Of Delivery
Scope of delivery The package includes: › 1 Off-line Filter Unit FNA 040 › 1 Operating manual Page 9 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 10: About This Product
About this product Performance specification The off-line filter unit FNA 040 is a stationary filter unit for filtration of hydraulic fluids and lubricants with a viscosity of 15 mm /s - 400 mm /s (in continuous operation). A separate installation in the bypass or cooling circuit for fine filtration and discharge of the full flow filter is just as possible as the filtration of fresh oil and the cleaning (flushing) of polluted systems for wear protection of components and systems. -
Page 11: Identification Of The Product
3 Filter fineness 6 Address NOTE Nameplates are documents which must not be changed or removed. › Damaged or lost nameplates immediately have to be replaced true to the original. Page 11 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 12: Transport And Storage
The ambient temperature during storage of the off-line filter unit FNA 040 should be between + 5 °C and + 30 °C at a humidity of 80 %. Before storage over a period of more than 6 months, the unit should be filled with oil in order to preserve it against corrosion. -
Page 13: Assembly
Specifically, proceed with the following steps: › connect the motor to the local power supply. Page 13 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 14: Commissioning
Check the off-line filter unit for leaks. In case of power failure In order to prevent unintentional starting of the unit, always switch off and unplug the unit. Page 14 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 15: Operation
Reaching the maximum cleaning performance › In order to prevent a short circuit of the oil flow, the distance between the suction and pressure connection should be kept as large as possible. Page 15 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 16: 10. Repair And Maintenance
The function of the filter unit is no longer guaranteed. › During repair work, all parts coming in contact with the hydraulic medium, must be kept free of dirt and chips. Page 16 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 17: Maintenance
2. Attach the filter element in arrow direction 2 and lock it in arrow direction 1. Fig. 6: Attaching the filter element Page 17 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 18: Replacing The Pump And The Motor
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during operation. › Allow the filter unit to cool down before touching it. Fig. 8: Replacing the motor and the pump Page 18 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... - Page 19 The device can be put into operation (see manual: Commissioning). If no oil is sucked during commissioning, open the cover at the filter housing and fill in about 0.3 l oil. Page 19 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN...
-
Page 20: Decomissioning
The final decommissioning and disposal requires complete uninstallation of the total energy supply, the mechanical components and the disposal of the hydraulic media remaining in the device. With disassembly and disposal, all national safety and environmental regulations must be observed. Page 20 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 21: 12. Disassembly
12. Disassembly The off-line filter unit is a device which does not have to be dismantled. Page 21 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 22: 13. Disposal
13. Disposal › Careless disposal of the off-line filter unit FNA 040 and the hydraulic fluid can lead to environmental pollution. › Therefore, dispose of the filter unit and the hydraulic fluid in accordance with the national regulations of your country. -
Page 23: 14. Troubleshooting
Replace suction hose or seal connection points (re-tighten them) Pump does not suck › Unit pumped empty Prime the unit (0.3 l) (with refilling) Table 7: Fault table Page 23 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 24: Technical Data
72 (under operating conditions permitted for continuous operation) 77 (under operating conditions permitted for short-term operation) Device dimensions see chapter 15.1 (length x width x height) Table 8: Technical data Page 24 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 25: Operating Conditions
400 V, 50 Hz, 10 - 16 Ampere 15.4 Hydraulic circuit diagram Fig. 10: Hydraulic circuit diagram 1 Pressure limiting valve 4 Motor 2 By-pass valve 5 Filter element 3 Pump 6 Clogging indicator Page 25 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 26: Connection Diagram
Electrical work on the off-line filter units has strictly to be carried out by qualified electricians. Connections Connections grounding grounding Delta connection Star connection Fig. 11: Connection plan Page 26 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 27: 16. Appendix
16. Appendix 16.1 Declaration of conformity Page 27 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... -
Page 28: Spare Parts List
(with parts 2 and 6) Filter element V7.1230-153 (with sealing) O-ring D25x3 N007.0253 Differential pressure switch DG 041-32 (with part 8) O-ring D4,5x1,5 N007.0041 O-ring D15x3 N007.00153/1 Table 9: Spare parts list Page 28 www.argo-hytos.com Subject to change · 27897500 · 10.2016 · EN... - Page 29 ARGO-HYTOS PVT. LTD. info.in@argo-hytos.com Italy ARGO-HYTOS S.r.l. info.it@argo-hytos.com Poland ARGO-HYTOS Polska spz o.o. info.pl@argo-hytos.com Russia ARGO-HYTOS LLC info.ru@argo-hytos.com Sweden ARGO-HYTOS Nordic AB info.se@argo-hytos.com Turkey ARGO-HYTOS Hid Ekip. San. ve Tic Ltd. Sti. info.tr@argo-hytos.com ARGO-HYTOS Inc. info.us@argo-hytos.com 27897500 · 10.2016 · EN...
