Manual
Off-line Filter Unit
FNA1HV
www.argo-hytos.com
Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN
Safety and operating instructions
Read safety and operating instructions before use.
Note:
The indicated data only serve to describe the product.
Specifications regarding the use of this product are only examples and suggestions.
Catalog specifications are no guaranteed features.
The information given does not release the user from his / her own assessments and inspection.
Our products are subject to a process of natural wear and aging.
© All rights are reserved by ARGO-HYTOS GMBH, even in the event of industrial property rights.
Any right of disposal such as copying and distribution rights shall remain with us.
The picture on the title page shows a configuration example.
The delivered product may thus differ from the illustration.
Page 1
Advertisement
Table of Contents
Related Manuals for Argo-Hytos FNA1HV
Summary of Contents for Argo-Hytos FNA1HV
- Page 1 Our products are subject to a process of natural wear and aging. © All rights are reserved by ARGO-HYTOS GMBH, even in the event of industrial property rights. Any right of disposal such as copying and distribution rights shall remain with us.
-
Page 2: Table Of Contents
Disassembly of the pump / motor ............................21 12.2 Installation of the pump / motor ............................22 12.3 Changing the filter element ............................... 23 Faultfinding / troubleshooting ............................26 Decommissioning / disposal ............................27 Page 2 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN... - Page 3 Annex ....................................28 15.4 Hydraulic circuit diagrams ..............................28 15.2 Connection diagrams ................................ 29 15.3 Spare parts lists ................................. 30 15.4 Installation declaration ............................... 32 Page 3 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN...
-
Page 4: About This Documentation
This documentation is applicable for the following product series: › Off-line Filter Unit FNA1HV 005; FNA1HV 008; FNA1HV 016 This documentation is written for technicians, operators, service engineers and system operators. This document contains important information for safe and appropriate assembly, transport, activation, operation, usage, servicing, dismantling and simple troubleshooting. - Page 5 In this documentation the following terms are used: Term Meaning FNA1HV Off-line Filter Unit Table 4: Terms 1.3.4 Abbreviations In this documentation the following abbreviations are used: Term Meaning Table 5: Abbreviations Page 5 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN...
-
Page 6: Safety Instructions
Therefore only use this product in safety-related applications if this use is explicitly specified and permitted in the product documentation, e.g. in explosion protection areas or in safety-related parts of a control system (functional safety). The ARGO-HYTOS GMBH assumes no liability for damages resulting from improper use. The risks associated with improper use are solely with the user. -
Page 7: General Safety Instructions
› Observe all instructions on the product. › People who assemble, operate, disassemble or maintain ARGO-HYTOS products may not do so under the influence of alcohol, other drugs or medications that affect the responsiveness. › Only use manufacturer-approved accessories and spare parts, in order to prevent personal danger due to unsuitable spare parts. -
Page 8: General Instructions
Danger due to improper handling Property damage › The off-line filter unit FNA1HV 005; FNA1HV 008; FNA1HV 016 may only be used in accordance with Section 2.2, “Intended use”. Leakage or spillage of hydraulic fluid Environmental pollution and ground water contamination. -
Page 9: Scope Of Delivery
Scope of delivery The package includes: › 1 Off-line Filter Unit FNA1HV 005 / FNA1HV 008 / FNA1HV 016 › 1 Operating manual › Mounting kit (rubber buffers, washers, nuts) Page 9 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN... -
Page 10: About This Product
About this product The off-line filter unit “FNA1HV 005 / FNA1HV 008 /FNA1HV 016“ is a filter system for filtering hydraulic fluids in the bypass flow. Type plate NOTE Type plates are documents; they must not be modified or removed. -
Page 11: Component Overview
5 Oil inlet port 2 Filter housing 6 Motor-pump unit 3 Filter element 7 Cable entries 4 Connection clogging indicator / 8 Oil outlet port clogging indicator Page 11 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN... -
Page 12: Transport And Storage
Treat all bare parts with preservatives. 6.2.2 Storage › Do not store the unit near flammable liquids or gases. › Do not store in the rain or in damp and wet environment. Page 12 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN... -
Page 13: Installation
A missing suction strainer can lead to destruction of the pump. In this case, the manufacturer assumes no liability. › With installation of the off-line filter units, a clogging indicator must be used. › Without a clogging indicator, element contamination is not detectable. Page 13 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN... -
Page 14: Mains Connection
Switch the unit off or disconnect it from the mains to avoid consequential damage to people and the environment when the voltage returns, e.g. due to overflowing oil or danger of slipping due to leaking oil. Page 14 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN... -
Page 15: Installation Recommendations
Min. fineness 600 µm e. g. order no. FA 016.0303 Keep the distance between suction and pressure side as large as possible (no short- Max. cleaning performance circuit of oil flow) Table 6: Installation recommendations Page 15 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN... -
Page 16: Operation Of The Off-Line Filter Unit
› Keep an adequate filtration time - recommended guideline values: 90 minutes per 100 l / 26.4 gal tank capactiy with FNA1HV 005 devices 60 minutes per 100 l / 26.4 gal tank capactiy with FNA1HV 008 devices 30 minutes per 100 l / 26.4 gal tank capacity with FNA1HV 016 devices Page 16 www.argo-hytos.com... -
Page 17: Technical Data
73 dB(A) under operating conditions allowed for continuous operation Noise intensity level max. 79 dB(A) under operating conditions allowed for short-term operation Table 7 : Technical data Page 17 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN... - Page 18 + DG 041-32 indicator Flange 60.30 optical DG 041.1200 Without clogging indicator * Indications at 50 Hz. At 60 Hz, the value increases by approx. 20%. Page 18 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN...
-
Page 19: Operating Conditions
Mains fuse 230 V, 50/60 Hz 10 A – 16 A 400/460 V, 50/60 Hz 10 A – 16 A Working position upright Table 8: Operating conditions Page 19 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN... -
Page 20: Maintenance
If dirt enters the pump during maintenance work, optimal functioning of the device is no longer guaranteed. In this case, the manufacturer assumes no liability! NOTE When performing any work: › Wear protective gloves, safety shoes and safety goggles! Page 20 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN... -
Page 21: Disassembly Of The Pump / Motor
Remove the pump plate (5) together with the wheel set (5.1) from the motor (9) and lift them upwards. Detach the motor (9) from the brackets. Dispose of old parts in an environmentally compatible way. Fig. 5: Exploded view of the off-line filter unit Page 21 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN... -
Page 22: Installation Of The Pump / Motor
0.3 l oil. If the electrical supply has been removed from the motor, connect it in accordance with the electrical circuit diagrams. Page 22 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN... -
Page 23: Changing The Filter Element
Dispose of the filter element in accordance with environmental regulations, waste code: OIL FILTER 16 01 07 Fig. 6: Releasing the fixture at the cover / filter element Page 23 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN... - Page 24 Fig. 7: Attaching the cover to the filter element NOTE › Oil that has accidently drained onto components of the off-line filter unit when changing the filter element, could be considered as leakage oil. Page 24 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN...
- Page 25 Attach the suction strainer (3) to the suction hose (2) according to Fig. 8 and secure it with the hose clamp (1). Fig. 8: Suction strainer FA 016.0303 Position Designation Order number Hose clamp DIN 03017 Suction strainer FA 016.0303 Table 10: Spare parts suction strainer FA 016.0303 Page 25 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN...
-
Page 26: Faultfinding / Troubleshooting
Oil is running out of the terminal box element change › › Screw connection is leaking Check screw connections, tighten / seal them if necessary Table 11: Fault table Page 26 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN... -
Page 27: Decommissioning / Disposal
Uninstallation of electrical components may only be carried out by qualified electricians. WARNING › Uninstallation of the filter and pumping-over unit may only be carried out by qualified electricians. › Risk of injury of any kind. Page 27 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN... -
Page 28: Annex
The hydraulic circuit diagram is only to be used for maintenance and repair works of off-line filter units. Type 1 (code OD) Type 2 (code ED) Type 3 (code EOD) Type 4 (code XD) Page 28 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN... -
Page 29: Connection Diagrams
Electrical connection of the off-line filter units may only be carried out by qualified electricians. Connections Connections Grounding Grounding Delta connection Star connection Type1 3~ delta connection Type 1 3~ star connection Connections 1~ Alternating current Type 2 1~ alternating current Page 29 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421 · EN... -
Page 30: Spare Parts Lists
15.3 Spare parts list 15.3.1 Spare parts drawing Fig. 9: Spare parts drawing FNA1HV Page 30 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN... - Page 31 FNA1HV 005...40050 43650100 FNA1HV 005...40050 Mounting set 34496400 All types Table 12: Spare part list Note: For other spare parts not listed in this manual please contact info.pl@argo-hytos.com Page 31 www.argo-hytos.com Subject to change · FNA1HV 005_008_016_43622600 · 0421· EN...
-
Page 32: Installation Declaration
32-640 Zator, Poland, declare on our sole responsibility that the products of product range Off-line Filter Unit FNA1HV 005; FNA1HV 008; FNA1HV 016 to which this declaration refers, conforms to the following standards and normative documents: Directive 2006/42/EC (Machinery Directive) - Page 33 India ARGO-HYTOS PVT. LTD. info.in@argo-hytos.com Italy ARGO-HYTOS S.r.l. info.it@argo-hytos.com Poland ARGO-HYTOS Polska spz o.o. info.pl@argo-hytos.com Russia ARGO-HYTOS LLC info.ru@argo-hytos.com Sweden ARGO-HYTOS Nordic AB info.se@argo-hytos.com Turkey ARGO-HYTOS Hid Ekip. San. ve Tic Ltd. Sti. info.tr@argo-hytos.com ARGO-HYTOS Inc. info.us@argo-hytos.com 04.2021 · EN...
