Manual
Filter Unit
FA 016
www.argo-hytos.com
Subject to change · FA 016_41299400 · 1016 · EN
Safety and operating instructions
Read safety and operating instructions before use.
Note:
The indicated data only serve to describe the product.
Specifications regarding the use of this product are only examples and suggestions.
Catalog specifications are no guaranteed features.
The information given does not release the user from his / her own assessments and inspection.
Our products are subject to a process of natural wear and aging.
© All rights are reserved by ARGO-HYTOS GMBH, even in the event of industrial property rights.
Any right of disposal such as copying and distribution rights shall remain with us.
The picture on the title page shows a configuration example.
The delivered product may thus differ from the illustration.
Page 1
Advertisement
Table of Contents
Related Manuals for Argo-Hytos FA 016
Summary of Contents for Argo-Hytos FA 016
- Page 1 Our products are subject to a process of natural wear and aging. © All rights are reserved by ARGO-HYTOS GMBH, even in the event of industrial property rights. Any right of disposal such as copying and distribution rights shall remain with us.
-
Page 2: Table Of Contents
Filter Unit FA 016 Contents Contents ..................................2 About this documentation ............................4 Applicability of this documentation ..........................4 Required and supplementary documentation ........................4 Presentation of information ............................. 4 1.3.1 Safety instructions ................................4 1.3.2 Symbols................................... 5 1.3.3 Terms ....................................5 1.3.4... - Page 3 Technical data................................30 16.3 Operating conditions ..............................31 16.4 Hydraulic circuit diagrams .............................. 31 Appendix ..................................32 17.1. Declaration of Conformity ............................. 32 17.2 Spare parts list ................................33 Page 3 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN...
-
Page 4: About This Documentation
This documentation is applicable for the following product: › Filter Unit FA 016 This documentation is written for technicians, operators, service engineers and system operators. This document contains important information for safe and appropriate assembly, transport, activation, operation, usage, servicing, dismantling and simple troubleshooting. -
Page 5: Symbols
In this documentation the following terms are used: Term Meaning Table 4: Terms 1.3.4 Abbreviations In this documentation the following abbreviations are used: Term Meaning Filter Unit Table 5: Abbreviations Page 5 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 6: Safety Instructions
Therefore only use this product in safety-related applications if this use is explicitly specified and permitted in the product documen- tation, e.g. in explosion protection areas or in safety-related parts of a control system (functional safety). ARGO-HYTOS GMBH assumes no liability for damages resulting from improper use. The risks associated with improper use are solely with the user. -
Page 7: General Safety Instructions
› Observe all instructions on the product. › People who assemble, operate, disassemble or maintain ARGO-HYTOS products may not do so under the influence of alcohol, other drugs or medications that affect the responsiveness. › Only use manufacturer-approved accessories and spare parts, in order to prevent personal danger due to unsuitable spare parts. -
Page 8: General Instructions
Do not use aggressive cleaning agents for cleaning. Clean the product with a suitable cleaning fluid. › Do not use a high pressure cleaner. › Do not use compressed air to clean function interfaces such as seal areas. Page 8 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 9: Scope Of Delivery
4. Scope of delivery The package includes: › 1 Filter Unit FA 016 › 1 Operating manual Page 9 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 10: About This Product
5. About this product Performance specification The filter unit FA 016 is a mobile filter unit for filtration of hydraulic fluids and lubricants with a viscosity of 15 mm /s - 200 mm (in continuous operation) in the bypass flow (400 mm /s max. -
Page 11: Identification Of The Product
3 Filter fineness 6 Address NOTE Nameplates are documents which must not be changed or removed. › Damaged or lost nameplates have to be replaced true to the original. Page 11 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 12: Transport And Storage
The ambient temperature during storage of the filter unit FA 016 should be between + 5 °C and + 30 °C at a humidity of 80 %. Before storage over a period of more than 6 months, the unit should be filled with oil in order to preserve it against corrosion. -
Page 13: Assembly
Specifically, proceed with the following steps: › connect the 230 V voltage plug to the local power supply. Page 13 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 14: Commissioning
Check the filter unit for leaks. In case of power failure In order to prevent unintentional starting of the unit, always switch off and unplug the unit. Page 14 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 15: Operation
7. Check the filling level at the machine or system and turn off the filter unit at the circuit breaker, once the desired filling quantity has been reached. 8. Re-attach the suction strainer and the discharge pipe at the appropriate brackets at the filter unit. Page 15 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 16: Filtering Liquids In The Bypass Flow
› In order to prevent a short circuit of the oil flow, the distance between the suction and pressure connection should be kept as large as possible. Page 16 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 17: Maintenance / Repair
The function of the filter unit is no longer guaranteed. › During repair work, all parts coming in contact with the hydraulic medium, must be kept free of dirt and chips. Page 17 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 18: Maintenance
V7.1220-13 (5 µm) the red range at a permissible viscosity V7.1220-06 (10 µm) Checking / changing the suction strainer FA 016.0110 quarterly or with corresponding problems (lower volume flow with clean filter element, too loud noise level). Table 6: Maintenance overview 10.2.1 Replacing the suction strainer... -
Page 19: Replacing The Filter Element
3. Screw in the cover manually until it stops. A gap between cover and filter pipe may remain visible (see Chapter 8.1 "Before commissioning" / Fig. 3) Fig. 8: Installing the filter element Page 19 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 20: Replacing The Pump
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be excee- ded during operation. › Allow the filter unit to cool down before touching it. Fig. 9: Replacing the motor and the pump Page 20 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 21: Removing The Pump
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during operation. › Allow the filter unit to cool down before touching it. Page 21 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 22: Removing The Motor
The device can be put into operation. If not oil is sucked during commissioning, open the cover at the filter housing and fill with about 300 ml oil. Page 22 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 23: Decommissioning
The final decommissioning and disposal requires complete uninstallation of the total energy supply, the mechanical components and the disposal of the hydraulic media remaining in the device. With disassembly and disposal, all national safety and environmental regulations must be observed. Page 23 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 24: Disassembly
12. Disassembly The filter unit is a device which does not have to be dismantled. Page 24 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 25: Disposal
13. Disposal › Careless disposal of the filter unit FA 016 and the hydraulic fluid can lead to environmental pollution. › Therefore, dispose of the filter unit and the hydraulic fluid in accordance with the national regulations of your country. -
Page 26: Extension
The suction strainer set FA 016.1775 consists of the suction strainer element 280 μm (2), a clip (3), a connection part with O-ring (4) and a connection piece (1). The suction strainer set FA 016.1775 is designed in a way, so that the DN 25 hose connection can be rotated by 360° and thus be adapted to the position of the pipe inlet. -
Page 27: Troubleshooting
Has the product or the device been operated correctly? » How does the fault tend to show? › Get a clear impression about the cause of trouble. Possibly consult the direct operator or machine operator. Page 27 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 28: Fault Table
Residual oil at the housing after Clean filter unit filter element change › Screwing leaky Check the screw joints, re-tighten and / or seal them Table 7: Fault table Page 28 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 29: Technical Data
16. Technical data 16.1 Device dimensions Fig. 11: Device dimensions Order No. Suction connection Pressure connection Dimensions FA 016-11000 ø 44 ø 20 FA 016-11010 ø 44 ø 20 FA 016-11100 ø 44 ø 20 FA 016-11110 ø 44 ø 20 FA 016-11300 ø... -
Page 30: Technical Data
Hose DN 20 with suction strainer, length 1.8 m Pressure side Hose DN 20 with discharge pipe, length 2.0 m 1 ~230 V Motor; 50 Hz; FA 016-11000, -11010, -11100, -11300, -11300F, -11600 0,45 kW, n=3.000 min Electric drive 1~110 V Motor; 50/60 Hz;... -
Page 31: Operating Conditions
Fig. 12: Hydraulic circuit diagram 1 Suction hose 6 Clogging Indicator 2 Suction strainer 7 Ventilating valve 3 Motor 8 Pressure limiting valve 4 Pump 9 Pressure hose 5 Filter Page 31 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 32: Appendix
17. Appendix 17.1 EC-Declaration of Conformity Page 32 www.argo-hytos.com Subject to change · FA 016_41299400 · 1016 · EN... -
Page 33: Spare Parts List
N007.0952 S Washer 8,4 118746005 ISO 7090 Hexagon nut M8 11874700 ISO 4032 Motor FA 016.1700 at FA 016-11000, -11110, -11300, -11600 FA 016.1715 at FA 016-11010, -11110, -11370 Tray FA 016.0101 Suction strainer FA 016.0301 Pressure hose FA 016.0107... - Page 34 ARGO-HYTOS PVT. LTD. info.in@argo-hytos.com Italy ARGO-HYTOS S.r.l. info.it@argo-hytos.com Poland ARGO-HYTOS Polska spz o.o. info.pl@argo-hytos.com Russia ARGO-HYTOS LLC info.ru@argo-hytos.com Sweden ARGO-HYTOS Nordic AB info.se@argo-hytos.com Turkey ARGO-HYTOS Hid Ekip. San. ve Tic Ltd. Sti. info.tr@argo-hytos.com ARGO-HYTOS Inc. info.us@argo-hytos.com V 0.2 · 10.2016 · EN...
