Extending Projector Ceiling Mount
Instruction Manual
SKU: MOUNT-VP02B/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vp02b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-VP02B
Summary of Contents for Vivo MOUNT-VP02B
- Page 1 Extending Projector Ceiling Mount Instruction Manual SKU: MOUNT-VP02B/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vp02b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
Outside Diameter CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR CEILING CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete. If unsure, please contact us at vivo-us.com, email at help@vivo-us.com, or call us at 309-278-5303. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 30lbs Failure to do so may result in serious injury. (13.61kg) Phillips Drill Screwdriver ASSEMBLY STEPS STEP 1 OPTION A: Run cables through Arm (A). OPTION B: If running cables through ceiling, pull cables through top plate of Arm (A). - Page 4 STEP 2 OPTION A: Wood Ceiling Joist Installation Use top plate of Arm (A) to mark mounting holes on ceiling. Using a 3/16” drill bit, drill approximately 2.2” into ceiling stud. Put Arm (A) in place and mount to the pre-drilled holes using Screws (W-A) and M6 OD-16 Washers (W-C) as shown in diagram.
- Page 5 STEP 2 (Continued) OPTION B: Concrete/Brick Mounting Use top plate of Arm (A) to mark mounting holes on ceiling. Using a ⅜” drill bit, drill approximately 2.4” into ceiling. Use Anchors (W-B), Screws (W-A), and M6 OD-16 Washers (W-C) to mount Arm (A) as shown in diagram.
- Page 6 STEP 3 Mount Bracket (B) to Arm (A) using Spacers (S-D), Plates (S-E), M5x12mm Screws (S-A), and Washers (S-B, S-C). Tighten using 4mm Allen Wrench (T-A).
- Page 7 STEP 4 Align arms on Mounting Bracket (C) with mounting holes in projector, and secure to projector using Screws (M-A through M-D) and Washers (M-E through M-H) most appropriate for your projector. If your projector has 3 mounting holes, simply remove one of the arms.
- Page 8 STEP 4 Cont.
- Page 9 STEP 5 Secure Mounting Bracket (C) using M5x12mm Screws (S-A), M5 OD-10 Washers (S-B) and M5 OD-10 Plastic Washers (S-C). Tighten with 4mm Allen Wrench (T-A). STEP 6 Adjust height and tilt of mount using the allen wrench (T-A). Adjustment #1: Use for pitched ceiling applications ONLY. Adjustment #2 &...
- Page 10 [PAGE INTENTIONALLY LEFT BLANK]...
- Page 11 [PAGE INTENTIONALLY LEFT BLANK]...
- Page 12 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
