Projector Ceiling Mount
Instruction Manual
SKU: MOUNT-VP07DP
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vp07dp
help@vivo-us.com
www.vivo-us.com
1-800-371-5654
Advertisement
Related Manuals for Vivo MOUNT-VP07DP
Summary of Contents for Vivo MOUNT-VP07DP
- Page 1 Projector Ceiling Mount Instruction Manual SKU: MOUNT-VP07DP Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vp07dp help@vivo-us.com www.vivo-us.com 1-800-371-5654...
-
Page 2: Tools Needed
NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR CEILING CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete. If unsure, please contact us at vivo-us.com, email at help@vivo-us.com, or call us at 1-800-371-5654. - Page 3 STEP 3 STEP 5 Push Clips (C) down over T-bar to hold the Ceiling Plate down. Attach Mount to Ceiling Plate at desired location using M6x18mm Bolts (G) with D6 Washers (F), and tighten with 5mm Allen Wrench (H). STEP 4 OPTION A: Insert cables through center of Mount (A) if cables will be hidden above ceiling.
- Page 4 STEP 7 STEP 9 Hang Bracket with projector over pre-installed screws on Mount, making sure plastic oval washers are Adjust angle and rotation of projector. positioned between the Bracket and Mount. STEP 10 (Optional) OPTION A: Wood Ceiling Installation Align holes in Mount (A) with wood stud and mark drilling locations. Use of a stud finder is recommended for finished ceilings.
- Page 5 Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
