  • Page 1 Extending Projector Ceiling Mount MOUNT-VP02B Series Assembly Manual Individual Product SKUs MOUNT-VP02B MOUNT-VP02W...
  • Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
  • Page 3: Package Contents

    Package Contents B (x1) C (x1) A (x1) Bracket Mounting Bracket Included Hardware & Tools M-A (x4) M-B (x4) M-C (x4) M-D (x4) M-E (x4) M3x8mm Screw M4x10mm Screw M5x10mm Screw M6x10mm Screw M3 Washer M-F (x4) M-G (x4) M-H (x4) S-A (x6) S-B (x6) M4 Washer...
  • Page 4: Assembly Steps

    Assembly Steps STEP 1 Option 1: Route Cables Through Arm Run cables through Arm (A) beginning at the hinge point, as shown below. Option 2: Route Cables Through Top Plate If running cables through ceiling, unfold the Arm (A) and pull cables through the Top Plate. Plate...
  • Page 5 STEP 2 Wood Stud Mounting ( see page 6 for Concrete/Brick mounting) Use top plate of Arm (A) to mark mounting holes on ceiling. Remove mount and pre-drill holes following instructions below. Pre-Drilling Instructions Drill mounting holes using illustration shown Drill Bit: 3/16”...
  • Page 6 Concrete/Brick Mounting Use top plate of Arm (A) to mark mounting holes on ceiling. Remove mount and pre-drill holes following instructions below. Pre-Drilling Instructions Drill mounting holes using illustration shown Drill Bit: 3/8” (10mm) Hole Depth: 2.4” (60mm) Use Anchors (W-B), ST6.3x55mm Screws (W-A), and M6 Washers (W-C) to mount Arm (A) as shown in diagram.
  • Page 7 STEP 3 Mount Bracket (B) to Arm (A) using Spacers (S-D), Plates (S-E), M5x12mm Screws (S-A), and Washers (S-B, S-C). Tighten using 4mm Allen Wrench (T-A).
  • Page 8 STEP 4 Loosen the four screws on the Mounting Bracket (C) using 4mm Allen Wrench (T-A) and unfold the Arms (C1). 4 Hole Mounting Patterns Align arms on Mounting Bracket (C) with mounting holes in projector and secure to projector using Screws (M-A through M-D) and Washers (M-E through M-H) most appropriate for your projector.
  • Page 9 3 Hole Mounting Patterns If you projector only has 3 mounting holes, use 4mm Allen Wrench (T-A) to remove one of the Arms (C1) from the Mounting Bracket (C). Align arms on Mounting Bracket (C) with mounting holes in projector and secure to projector using Screws (M-A through M-D) and Washers (M-E through M-H) most appropriate for your projector.
  • Page 10 STEP 5 Secure Mounting Bracket (C) to Bracket (B) using M5x12mm Screws (S-A), M5 Washers (S-B) and M5 Plastic Washers (S-C). Tighten with 4mm Allen Wrench (T-A).
  • Page 11: Height Adjustment

    Adjusting Height & Tilt Forward Tilt Side to Side Tilt 1. Height Adjustment 2. Tilt Adjustment Use 4mm Allen Wrench (T-A) to Use 4mm Allen Wrench (T-A) to loosen joint to loosen joint to adjust height. adjust tilt angle. Tighten joint to set. Tighten joint to set.
  • Page 12 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
