Black Projector Ceiling Mount
Instruction Manual
SKU: MOUNT-VP06B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vp06b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo MOUNT-VP06B
Summary of Contents for Vivo MOUNT-VP06B
- Page 1 Black Projector Ceiling Mount Instruction Manual SKU: MOUNT-VP06B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vp06b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...
-
Page 2: Package Contents
NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR CEILING CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete. If unsure, please contact us at vivo-us.com, email at help@vivo-us.com, or call us at 309-278-5303. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 44lbs Failure to do so may result in serious injury. (19.96kg) Phillips Drill Screwdriver ASSEMBLY STEPS STEP 1 Route cables through telescopic pole (B). Route cables through ceiling plate (A). Attach ceiling plate to telescopic pole using M6x10 screws (M-B) and D6 washers (M-J), and tighten with large Allen wrench (M-L). - Page 4 STEP 2 OPTION A: Wood Ceiling Installation Position ceiling plate against ceiling and mark drill locations with a pencil. Use of a stud finder is recommended with wood beam ceilings. Drill 2.2” (55mm) deep holes using a 3/16” (4.5mm) drill bit. Mount ceiling plate using screws (W-A) and washers (W-C).
- Page 5 STEP 3 Install projector mounting bracket (D) to projector using appropriate screws (M-C, M-D, M-E) and washers (M-F, M-G, M-H). For projectors with uneven mounting holes, swap appropriate arm extensions with alternate extensions (M-M). Please note, if your projector has only three mounting holes, simply leave one mounting arm unused.
- Page 6 STEP 5 Adjust tilt angle and secure with small Allen wrench (M-K). M- K +8° -8° STEP 6 Attach mounting bracket (C) to telescopic pole in alternate position using x4 M5x10 screws (M-A) and x4 D5 washers (M-H), and tighten with small Allen wrench (M-K). M- A M- H M- K...
- Page 7 STEP 8 Install projector mounting bracket (D) to projector using appropriate M-C/M-D/M- E screws (M-C, M-D, M-E) and washers M-F/M-G/M- H M- M (M-F, M-G, M-H). For projectors with uneven mounting holes, swap appropriate arm extensions with alternate extensions (M-M). Please note, if your projector has only three mounting holes, simply leave one mounting arm unused.
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
