Polycom RealPresence Medialign 255 Slimline Base Assembly And Wiring Instructions page 14

Cable No.
C.1
C.2
C.3
C.4
C.5
C.6
C.7
C.8
C.9
Cable No.
C.10
C.11
C.12
C.13
C.14
C.15
C.16
C.17
C.18
Cable No.
IN.1
IN.2
IN.3
IN.4
© 2016, Polycom, Inc. All rights reserved. POLYCOM® and the names and marks associated with Polycom's products are trademarks and/or service marks of Polycom, Inc. and are registered and/or
common law marks in the United States and various other countries. All other trademarks are property of their respective owners.
All manuals and user guides at all-guides.com
RealPresence® Medialign
Description QTY From
Left speaker audio 1 abox Left Speaker
Left speaker power 1 abox Left Speaker
Right speaker audio 1 abox Right Speaker XLR-5pin
Right speaker power 1 abox Right Speaker
abox to screen 1 video 1 abox screen 1 (right)
abox to screen 1 power 1 abox (R) screen 1 (right)
abox to screen 2 power 1 abox (L) screen 2 (left)
Mains input cable (US) 1 Plug (US)
Network input cable 1 wall
RealPresence Medialign 255 Codec And Bracket Set
Description QTY From
codec content in 1 abox codec
codec audio in 1 abox codec
codec audio out 1 codec
codec network 1 abox codec
codec control 1 abox codec
screen input 1 codec (2) Screen 1 (right)
screen input 1 codec (1) Screen 2 (left)
codec power 1 abox (right) PSU (right side) IEC C13
Producer power 1 abox (left) PSU (left side)
RealPresence Medialign interface-s Cable Set
Description QTY From
Interface-s to abox 1 interface-s
HDMI Input 1 interface-s User Laptop
VGA Input 1 interface-s User Laptop
Audio Input 1 interface-s User Laptop
255 Core Cable Kit
™
Connectors
To
From Color To Color
XLR-5pin Black XLR-3pin Black
C7 Black C8 Black
Black XLR-3pin Black
C7 Black C8 Black
HDMI Purple HDMI Brown
M12 Yellow M12 Yellow
M12 Yellow M12 Yellow
abox US Plug Black IEC Black
abox RJ45 Black RJ45 Black
Connectors
To
From Color To Color
HDMI Green HDMI Green
3.5mm Green 3.5mm Green
abox 3.5mm Blue 3.5mm Blue
RJ45 Blue RJ45 Blue
D9 Red DIN Red
HDMI Blue DVI Green
HDMI Red DVI Green
Black IEC C14 Black
IEC C13 Black IEC C14 Black
Connectors
To
From Color To Color
abox DVI-I Black DVI-I Black
HDMI Black HDMI Black
VGA Black VGA Black
3.mm Jack Black 3.mm Jack Black
Length
Part Number
m
2.40 ABC-506-040738-8281
2.80 ABC-506-040738-8410
1.80 ABC-506-040738-8304
1.80 ABC-506-040738-8311
1.5 ABC-506-032414-8616
1.65 ABC-506-027694-8197
2.85 ABC-506-027694-8432
3.00
ABC-506-046660-0928
3.00 ABC-506-027694-9569
Length
Part Number
m
1.10 ABC-506-040738-8342
1.05 ABC-506-040738-8366
1.05 ABC-506-040738-8380
0.90 ABC-506-040738-8403
0.90 ABC-506-040738-8427
1.30 ABC-506-040738-8441
3.00 ABC-506-032414-8654
1.00 ABC-506-040738-8472
1.50 ABC-506-040738-8373
Length
Part Number
m
5.00 ABC-506-027694-8265
1.00 ABC-506-027694-8715
1.00 ABC-506-046660-0782
1.00 ABC-506-032414-8630
14
