User Manual

XTOXLnie/ XTOXLnce

USER MANUAL

XTOXL4ie / XTOXL5ie / XTOXL6ie

XTOXL4ce / XTOXL5ce / XTOXL6ce

LH-RH versions

Thermal Transfer Overprinter (TTO) for large areas,

configurable for intermittent or continuous operation

This manual contains the EC Declaration of Conformity

Edition A - 01/2024

Original Instructions - keep for future reference

RT823

Table of Contents

Need help?

Do you have a question about the EIDDOS XTOXLnie and is the answer not in the manual?

Questions and answers

Summary of Contents for Novexx Solutions EIDDOS XTOXLnie

Page 1 User Manual XTOXLnie/ XTOXLnce USER MANUAL XTOXL4ie / XTOXL5ie / XTOXL6ie XTOXL4ce / XTOXL5ce / XTOXL6ce LH-RH versions Thermal Transfer Overprinter (TTO) for large areas, configurable for intermittent or continuous operation This manual contains the EC Declaration of Conformity Edition A - 01/2024 Original Instructions - keep for future reference RT823...
Page 3: Table Of Contents
User Manual XTOXLnie/ XTOXLnce Contents Information ..........................2 NOTES ON THE CORRECT USE OF THE PRINTER ................2 GENERAL NOTES ..........................2 SAFETY NOTICES ..........................3 GENERAL PRECAUTIONS ........................3 DANGEROUS AREAS ON THE PRINTING UNIT .................. 4 PROTECTION ELEMENTS PROVIDED ....................7 Product Description .........................
Page 4: Information
User Manual XTOXLnie/ XTOXLnce Information NOTES ON THE CORRECT USE OF THE PRINTER Read these notes together with Chapter “Safety notices" to ensure that the printer is used correctly. Switching on the printer. • If the printer has been left in a cold or excessively hot environment for a considerable time, wait at least 1 hour before switching it on to prevent humidity collecting on the internal circuits.
Page 5: Safety Notices
User Manual XTOXLnie/ XTOXLnce How information is represented Explanation of symbols WARNING! A warning symbol refers to risks that can result in severe or fatal injuries! The text within this area contains instructions for preventing damage. ➔ Instructions must be followed without exception. WARNING! The text within this area contains important recommendations as well as additional information or information to use the product correctly and efficiently.
Page 6: Dangerous Areas On The Printing Unit
User Manual XTOXLnie/ XTOXLnce DANGEROUS AREAS ON THE PRINTING UNIT Dangerous areas - front and bottom view Figure 1: dangerous areas - front view (RH version shown) Figure 2: dangerous areas – bottom view (RH version shown) Note: if in intermittent mode, during the installation it is necessary to fix the printing plate and the printing unit so that the plate prevents finger access to the areas [A] and [B] where the carriage with the print head moves.
Page 7 User Manual XTOXLnie/ XTOXLnce Dangerous areas - rear view Figure 3: Dangerous areas - rear view Dangerous areas on - side views Figure 4: Dangerous areas - side views Dangerous areas - carriage. Figure 5: Dangerous areas - carriage Edition A - 01/2024 Information...
Page 8 User Manual XTOXLnie/ XTOXLnce Passive (non-motorized) rotating rollers Figure 6: free rollers Definitions Movement of the carriage during printing or positioning in the "Service" area. Danger of crushing the fingers Movement of the carriage when returning to Home after printing or during a return from "Service".
Page 9: Protection Elements Provided
User Manual XTOXLnie/ XTOXLnce PROTECTION ELEMENTS PROVIDED Covers fixed with screws Figure 7: fixed cover WARNING! Disconnect the 48Vdc power supply to the printer before removing the fixed guards [RF1], [RF2], [RF3]. The fixed guards must be removed only for extraordinary maintenance or repairs.
Page 10 User Manual XTOXLnie/ XTOXLnce Monitoring sensors movable guard [RM1] inserted SENS4 Magnetic sensor SENS_C1 Figure 9: monitoring sensors External safety contacts: SAFETY_A and SAFETY_B (SAF_EXT) NOTE: If not used, they must be jumpered. [SAF_EXT] SAFETY_A SAFETY_B SAFETY_SAF Figure 10: safety contacts Magnets and magnets ring To ensure good fastening of the movable guard [RM1] to the printing unit, magnets [mg1], [mg2] have been provided on the printer body and magnetic rings [am1], [am2] on the ribbon inserter.
Page 11 User Manual XTOXLnie/ XTOXLnce Fixed guard but not solidly screwed to the Printing Unit (only for intermittent mode) The Printing Plate [PP] cannot be strongly screwed to the Printing Unit [PU] because it is necessary to leave the passage to the packaging film [PF] to be printed. [PU] [PF] [PP]...
Page 12 User Manual XTOXLnie/ XTOXLnce Figure 14: printing plate alignment Warning symbols on the machine CAUTION! Warning symbols on the machine provide important information for the operating personnel. ➔ Do not remove warning symbols. ➔ Replace missing or illegible warning symbols. Meaning of the warning symbols: Warning symbol Meaning...
Page 13: Product Description
User Manual XTOXLnie/ XTOXLnce Product Description FUNCTIONALITY The XTO XL series is an electronic printer for "thermal transfer to film" that is able to write automatically and directly on the plastic or paper film used in packaging machines by means of an inked thermal ribbon.
Page 14: Carriage Stroke Lengths And Machine Type
User Manual XTOXLnie/ XTOXLnce CARRIAGE STROKE LENGTHS AND MACHINE TYPE Models Max. Print Area XTOXL4.ie 107 x 100 mm intermittent XTOXL5.ie 128 x 100 mm XTOXL6.ie 160 x 100 mm XTOXL4.ce 107 x 990 mm continuous XTOXL5.ce 128 x 990 mm XTOXL6.ce 160 x 990 mm The printer can be supplied in 2 versions.
Page 15: System Configurations
User Manual XTOXLnie/ XTOXLnce SYSTEM CONFIGURATIONS 7XTOXLnienn-1 /7XTOXLncenn-1 XTOXL 45CV910/1 49KS0162 L = 7 m* +48Vdc 320W 45CV914/1 (capacitor kit to be connected on the 48Vdc power supply V+/V- output pins) 7XTOXLnienn-2 /7XTOXLncenn-2 XTOXL 49KS0162 45CV932/1 + CE300434 7XTOXLnienn-3 /7XTOXLncenn-3 XTOXL 45CV910/1 49KS0162...
Page 16 User Manual XTOXLnie/ XTOXLnce IP Version: 7XTOXLnienn-1TR / 7XTOXLnienn-1IP 7XTOXLncenn-1TR / 7XTOXLncenn-1IP 45CV910/1 L = 7 m* 48Vdc-320W L = 7 m*** 45CV914/1 (capacitor kit to be connected on the 48Vdc power supply n = 4, 5 or 6 (printhead type) V+/V- output pins) nn = LH or RH * = see note on previous page...
Page 17 User Manual XTOXLnie/ XTOXLnce 53SDK21 Touch panel It is a 7 "TFT colour graphic display with capacitive touch connected via ethernet to the printer, from which it is also powered. To fix the EIDOS Touch Panel to the packaging machine, a hole must be made, to be made as per the drawing below.
Page 18: Rear Connection Panel
User Manual XTOXLnie/ XTOXLnce REAR CONNECTION PANEL WARNING! This printer operates using 48Vdc – 320W voltage! Touching live electrical parts may expose you to hazardous electrical currents and may lead to burns. ➔ Make sure that the printer is switched off before connecting the power cable. ➔...
Page 19: Operating Panel
User Manual XTOXLnie/ XTOXLnce OPERATING PANEL The operating panel is a comfortable external control panel for the XTOXL, which can be operated display devices. You can use the 59SDK18 device or a PC. Prerequisites • Display device, e.g. 59SDK18, Raspberry, tablet, PC •...
Page 20 User Manual XTOXLnie/ XTOXLnce Shortcut (goes to the page containing the Go to Production Performance page view most used commands) Shows label or LMT labels (1-2-3- 4) Ready mode Figure 22: Ready mode view Remote view status (the black eye appears Print direction when the user is logged with "view only"...
Page 21 User Manual XTOXLnie/ XTOXLnce Production Performance page view [13] In this page, the print job in progress can be monitored. Data relating to the XTOXLnie printer Data relating to the XTOXLnce printer Figure 24: production view Print counter Current date and time The animation runs when a print command 28a- Print rate: number of prints per minute.
Page 22: Basic Settings
User Manual XTOXLnie/ XTOXLnce BASIC SETTINGS Settings in the Parameter Menu Level 0 allows the operator to set the parameters necessary for printing the label. This level is always accessible. Figure 25: level 0 parameters Load new label Set counters Load packaging format Printer Set up Password protection...
Page 23 User Manual XTOXLnie/ XTOXLnce Load new label Figure 26: load label Select the drive and load new label. You can use an FTP client (such as WinSCP) to copy the desired layout files to the "FLASH C:ftp" subdirectory. The settings to connect to XTO with FTP are: IP: the IP of the XTO Port: 21 User: ftp...
Page 24 User Manual XTOXLnie/ XTOXLnce By clicking on the second button you can set the counters. Figure 29: set counters This page is also accessible by the same icon on the Parameters menu. Load Packaging format Click to load the selected PAF Click to select the PAF file Figure 30: load PAF parameters...
Page 25 User Manual XTOXLnie/ XTOXLnce The printer can print labels on multi tracks packaging film. To do this you must set how many tracks must be printed and the pitch between each printed image on film. Save as a new PAF Save current PAF file Figure 31: PAF creation Print Home shift: increase this parameter to get a shift of the printed image in the direction of the...
Page 26 User Manual XTOXLnie/ XTOXLnce Printing Num. Every Cycle: it sets a limit to the maximum number of labels printed in case of LMT repetition. For example: you have a .LMT file of 4 labels and you want to repeat it twice but you need only 7 labels instead of 8 (4 x 2);...
Page 27 User Manual XTOXLnie/ XTOXLnce PRINT HOME SHIFT (for XTOXLnie) The "Print Home Shift" parameter allows to shift the print position start in direction of the carriage movement during print. "Print Home Shift" = 0 means that the print starts from carriage Home position.
Page 28: Operation
User Manual XTOXLnie/ XTOXLnce Operation INSERTING CONSUMABLES How to load the thermal ribbon Biadhesive layer Figure 34: ribbon passage How to operate • Remove the front cover [1] • Remove the used ribbon. • Clean the rubberized ribbon roller [R1] using alcohol to have a good grip with the ribbon. •...
Page 29: The Thermal Ribbons
User Manual XTOXLnie/ XTOXLnce THE THERMAL RIBBONS Smart-Black - XTOXL series ribbon The XTOXL ribbons selection include two different wax-resin products (standard and special) available in 1200m length and two different resin alternatives (standard and special) available in 1000m length. Moreover, is possible to print on craft films by a special ribbon. All the ribbons are winded on 1 inch plastic core, ink IN.
Page 30: Printing
User Manual XTOXLnie/ XTOXLnce PRINTING Description of operation (Refer to Chapter “Product Description – Operating Panel” of this manual.) Switch on the printer and wait for the programme loading phase. The printer can receive the commands from the production line if it is in READY (automatic) status. Load the label to be printed.
Page 31: Creation And Sending Of The Label With Easycode
User Manual XTOXLnie/ XTOXLnce Starting and Monitoring a Print Job The printer starts to print, as soon as the following conditions are met: • The display shows the “READY” screen • An STA digital input pulse is received If the printer shows the “MAN” screen: ➔...
Page 32 User Manual XTOXLnie/ XTOXLnce Label transmission to XTOXL with LAN connection With the EASYCODE software license "R" version, you can create, modify, save labels and send them to EIDOS and no-EIDOS printers by means of their Windows driver via LAN network connection. How to operate ➔...
Page 33: How To Store Label Files (.Lm1)
User Manual XTOXLnie/ XTOXLnce HOW TO STORE LABEL FILES (.LM1) Insert the memory key containing the label .LM1 files. Put the printer in MANUAL mode and enter the Parameter Setting. • Click on “File management” button • Click on “Copy files”. •...
Page 34: Setting And Monitoring
User Manual XTOXLnie/ XTOXLnce SETTING AND MONITORING Printer Parameters: general information From the main menu, with the printer in the MAN position, you access the parameter page, where you can adjust the printer. Figure 41: Login To access the desired level, select the level (from 0 to 3) on the left of the screen, enter username and password and press Login.
Page 35 User Manual XTOXLnie/ XTOXLnce Add user and password At the first installation, access to levels 1 and 2 will be password-free. If you want to restrict access to users, you must set a level 2 password. Afterwards, only by logging in with this password, it will be possible to create additional level 1 and 2 passwords for the desired users.
Page 36 User Manual XTOXLnie/ XTOXLnce Printer Parameters: added with Level 1 File management Copy files or folders Disk A and Disk B are the USB memory key Create directory inserted in the USB-A and USB-B connectors. Disk C: is the internal printer CPU disk. Font C: folder containing the fonts, on the printer.C: folder c Font C: folder containing Copy All menu...
Page 37 User Manual XTOXLnie/ XTOXLnce Back up Figure 47: back up Insert the memory card on which to store the data and click on "Make Back up” button. Repeat the back-up procedure periodically and in any case, after making substantial changes to the parameters Note: folders are highlighted in yellow.
Page 38 User Manual XTOXLnie/ XTOXLnce Update File System Upgrade Procedure → Copy the pxtox_x.x.xxxx.tar file containing the software update onto the USB key and insert it into the USB port of the printer. Note: Do not unpack the file but use it as a .tar. The file can be copied to the root directory or to a subfolder.
Page 39 User Manual XTOXLnie/ XTOXLnce → Answer "YES" to the question Wait a few minutes. At the end of the operation the printer will automatically restart with the new software aboard. → If the update was not carried out correctly, the error is indicated with the X icon in a red field. In this case repeat the operation by clicking again on the "Update"...
Page 40 User Manual XTOXLnie/ XTOXLnce Set Printer Parameters This menu allows adjustment of the basic parameters. after making the desired adjustments, press the save button to make them effective. Printer parameters in intermittent mode Figure 50: Printer Parameter - intermittent mode, part A Edition 01 - 11/2022 Operation...
Page 41 User Manual XTOXLnie/ XTOXLnce Figure 51: Printer parameter – intermittent mode, part B NOTE! The description of the parameters is in the Technical Manual (RT824) and, by clicking on the button you can view the help of each parameter. ➔ by clicking on the pencil symbol it will be possible to set the value step by step as an alternative to the adjustment bar.
Page 42 User Manual XTOXLnie/ XTOXLnce Printer parameters in continuous mode Figure 52: Printer Parameter - continuous mode, part A Edition 01 - 11/2022 Operation...
Page 43 User Manual XTOXLnie/ XTOXLnce Figure 53: Printer Parameter - continuous mode, part B NOTE! The description of the parameters is in the Technical Manual (RT824) and, by clicking on the button you can view the help of each parameter. ➔ by clicking on the pencil symbol it will be possible to set the value step by step as an alternative to the adjustment bar.
Page 44 User Manual XTOXLnie/ XTOXLnce Label The label parameters are automatically updated in the printer every time a new .LM1 file is loaded. These label dimensions and parameters must be set (with EASYCODE program) during the label creation. The label .LM1 file parameters in this page are view only. Figure 54: label parameters view - Width X: label dimensions in the parallel direction to the print head dots line.
Page 45 User Manual XTOXLnie/ XTOXLnce Set Date/Time Figure 55: calendar Printer diagnostic Figure 56: diagnostic menu The buttons on the first grey strip allow you to view and adjust the diagnostic parameters. Load new label: a new label is loaded Label preview: the label is displayed System diagnosis: (see following pages) Edition 01 - 11/2022 Operation...
Page 46 User Manual XTOXLnie/ XTOXLnce C1-2 Figure 57: printer diagnostic page Press to activate/deactivate an OUTPUT Green = Output ON Grey = Output OFF Yellow = Input ON Grey = Input OFF [Only for Continuous mode] ENCODER: status of PHASE A and PHASE B of the encoder port on the rear panel of the printer unit.
Page 47 User Manual XTOXLnie/ XTOXLnce Figure 59: TPH – diagnostic page INTERMITTENT mode printer Press to activate/deactivate the Green lamp on front switch button Press to make ON the Press to activate/deactivate the Red internal led lamp lamp on front switch button Yellow = Input ON Grey = Input OFF Figure 60: front panel -intermittent model (RH version)
Page 48 User Manual XTOXLnie/ XTOXLnce CONTINUOUS mode printer Press to activate/deactivate the Green lamp on front switch button Press to make ON the Press to activate/deactivate the Red internal led lamp lamp on front switch button Yellow = Input ON Grey = Input OFF Figure 61: front panel - continuous model (RH version) Yellow = Input ON Grey = Input OFF...
Page 49 User Manual XTOXLnie/ XTOXLnce The buttons on the bottom strip allow you to test the printer. Print grid: Print test to check if the print head has some broken dots or if the print head and the print plate or roll are perfectly aligned in the whole print area size.
Page 50 User Manual XTOXLnie/ XTOXLnce Printer Parameters: added with Level 2 Set I/O parameters. Only for Continuous mode Only for Intermittent mode Figure 63: I/O management Print Command “STA” 0 = Front OFF-ON (default) 1 = Front ON-OFF 2 = Level ON 3 = Level OFF Print command check Default = enabled...
Page 51 User Manual XTOXLnie/ XTOXLnce In presence of many print command signal bounces, it is advised to increase this parameter value over 2 to filter more the print command signal. In case the number of bounces received is still higher than the number set the E232 will appear. End of Print (FAP) output type Pulse (default).
Page 52 User Manual XTOXLnie/ XTOXLnce Disable Print Command whit C2S When this function is enabled the print STA digital command is rejected as long as C2S input is activated and warning appears on the screen. Set IP parameters: Figure 64: communication parameters If the Wait Ready function is enabled, W character is emitted when the print cycle starts and R character is emitted when the print cycle is finished (before the carriage comes back to home) or immediately when an error occurs during print.
Page 53 User Manual XTOXLnie/ XTOXLnce Set TPH calibration: printer in INTERMITTENT mode IMPORTANT! it is advised to make the TPH calibration with the packaging film overposed on the printing plate to take in account the thickness of the film. Shows the %value during the calibration Shows the current...
Page 54 User Manual XTOXLnie/ XTOXLnce Press the relative “calibration” key to move the carriage at the desired position (SERVICE/MIDDLE/HOME) and start the calibration. If the indication under the symbol is green, the calibration is OK. If it is red, the calibration is not OK. The value detected is coloured red when it is 2% higher or lower than the average value between the values detected (SERVICE/MIDDLE/HOME).
Page 55 User Manual XTOXLnie/ XTOXLnce Set TPH calibration: printer in CONTINUOUS mode WARNING! this operation must be performed with the packaging line stopped. Shows the % value during the calibration Shows the current value during the calibration Figure 67: TPH calibration page – continuous mode (RH version) move TPH down (Ready to print position) move TPH up (Ribbon change operation position) move TPH in print position for 5 seconds...
Page 56 User Manual XTOXLnie/ XTOXLnce In any case, always carry out a print test to find the point of tangency of the print head to the roller that offers the best print quality. After performing a calibration the “TPH FORCE” Print parameter will be set at the value detected by the calibration, with the possibility of reducing the value or increase the value in a range of +/- 10%.
Page 57 User Manual XTOXLnie/ XTOXLnce • NiceLabel Emulation setting Figura 69: emulators setting NiceLabel Emulation: enable this function to receive files as NICELABEL ZPLII protocol. The label transmission can only take place via Ethernet LAN (not managed from USB key). If NiceLabel emulation is active, the setting parameter is also displayed in the Manual mode page.
Page 58 User Manual XTOXLnie/ XTOXLnce Set ribbon Only for intermittent model Figure 71: Ribbon setting Set the code of the EIDOS ribbon used. The setting of the used ribbon code requires that some specific parameters of the printer are automatically set in the optimal way for the ribbon in use (e.g. Enhanced Mode, Accelerations, Jerk etc).
Page 59: Status Messages
User Manual XTOXLnie/ XTOXLnce STATUS MESSAGES General information about status reports During operation, tests are continually carried out to determine whether a malfunction has occurred. If a malfunction is detected, the corresponding status report appears on the display. The list of messages, complete with their description, is shown in the document "RT578 - Error messages and troubleshooting".
Page 60 User Manual XTOXLnie/ XTOXLnce Help icon: after pressing the icon, a quick troubleshooting guide appear. Figure 74: Troubleshooting guide Error text: each error number has a status text in the language of the control panel. Diagnosis icon: pressing the button, you are sent to the appropriate diagnostic page. Pause: it unlocks the error message (not the error) to allow access to the diagnostic pages.
Page 61: Preventive Maintenance
User Manual XTOXLnie/ XTOXLnce Preventive Maintenance CLEANING INSTRUCTIONS WARNING! Dangerous situations may arise during maintenance and cleaning work. Accidents may occur if the relevant safety instructions are not observed! ➔ Switch off the machine before cleaning or maintenance and pull out the mains power connecting line! ➔...
Page 62: Cleaning The Print Head
User Manual XTOXLnie/ XTOXLnce CLEANING THE PRINT HEAD Switch off and lock out the printer before performing this task! You are advised to clean daily the printing line of the thermal head located on the printing unit. Clean the fixed pin [P] located on the left side of the printing head.
Page 63: Cleaning The Printing Plate (Xtoxl Intermittent)
User Manual XTOXLnie/ XTOXLnce CLEANING THE PRINTING PLATE (XTOXL Intermittent) Clean with a cleaning tissue or with a paper tissue soaked in isopropyl alcohol. Advisable when the printer is in fixed position. How to operate Switch off the printer and remove the rolls of thermal ribbon.
Page 64: Cleaning Rolls And Ribbon Passages
User Manual XTOXLnie/ XTOXLnce CLEANING ROLLS AND RIBBON PASSAGES Check the status of rubberized ribbon encoder roll [R1]. Verify that the surface of the roll is smooth and even. Check every single roll turn without jamming and is not crooked. Note: It is very important to clean the rubber coated roll and to check sometimes that it rotates freely, to avoid print overposition on the ribbon with bad print quality or missing parts in print.
Page 65: Ec Declaration Of Conformity
User Manual XTOXLnie/ XTOXLnce Appendix 1 EC DECLARATION OF CONFORMITY Manufacturer: EIDOS Srl – via dell’Industria,11 - 10023 Chieri (TO) ITALY – www.eidos.eu Person authorised to compile the technical file: Paolo Bori – via dell’Industria, 11 – 10023 Chieri (TO) Declares regarding the following supply Generic Denomination and Function: Intermittent Thermal Transfer Overprinter (TTO) XTOXL “e”...
Page 66: Ce Label
User Manual XTOXLnie/ XTOXLnce Appendix 2 CE LABEL Attach the label here 1) System model 2) Mechanical unit 3) Electronic unit 4) Serial number 5) Production date CE Label position on Mechanical Unit CE label Edition A - 01/2024 Appendix 2...
Page 67: Zebra And Eidos Nicelabel Emulation File Management (.Prn, .Zpl)
User Manual XTOXLnie/ XTOXLnce Appendix 3 ZEBRA and EIDOS NICELABEL EMULATION FILE MANAGEMENT (.prn, .zpl) On the XTO XL series printer it is possible to load all ZEBRA and EIDOS NICELABEL label files, with .ZPL, .zpl, .PRN, .prn extension. Following, an example of ZEBRA file. ^FT61,91^A0,40,40 ^FD809098987876543123^FS ^PQ1,0,1,Y^XZ...
Page 68 User Manual XTOXLnie/ XTOXLnce Managing .prn files containing ZPL language with XTOXL The .prn files can be uploaded to the printer from USB key or copied and stored in the printer's C: memory. How to operate: - Enabling the Zebra/Nicelabel Emulator At this point, from File Management you can also manage .prn files.
Page 69 User Manual XTOXLnie/ XTOXLnce Loading label in Zebra or NiceLabel formats - If the .prn file is a template containing text defined as variables (^FNn) to be filled with the ^FNnxxxxx command, it can be compiled locally by the operator with the SDK18 touchpanel. Edition A - 01/2024 Appendix 3...
Page 70 User Manual XTOXLnie/ XTOXLnce Management of .prn files with "Enable Page I/O" function If it is enabled, the emulator allows the "Enable pages from I/O" feature to be used for Zebra or NiceLabel format labels as well. How to operate: - Enabling the Zebra/Nicelabel Emulator - Enable the "Enable Page I/O"...
Page 71 User Manual XTOXLnie/ XTOXLnce Only in the case of loading Zebra/NiceLabel files, it is possible to change the "Width X" and "Length Y" parameters of the label from the "Label Parameters View" page. The change will take effect by pressing the save button at the top of the page. These parameters will be overridden by ^PW (Print Width) and ^LL (Label Length) commands that may be present in the layout, unless the "Ignore ZPLII Label dimension"...
Page 73 Thank you for taking the time to read this manual we recommend you keep it for future reference.
Page 74 Via dell’Industria, 11 Z.I. Fontaneto 10023 Chieri (TO) ITALY e-mail: eidos@eidos.eu web: www.eidos.eu...
