Gigabit Ethernet Switch – Basic Line
IE-SW-BL05-5GT
Hardware Installation Guide
Third Edition, July 2011
1243380000/02/07.11
Please note:
This document and any further product information - if
available - can be downloaded at the internet link:
http://www.weidmueller.com/downloads
Copyright Notice
Copyright © 2011 Weidmüller Interface GmbH & Co. KG
All rights reserved.
Reproduction without permission is prohibited.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weidmüller IE-SW-BL05-5GT
Summary of Contents for Weidmüller IE-SW-BL05-5GT
- Page 1 Gigabit Ethernet Switch – Basic Line IE-SW-BL05-5GT Hardware Installation Guide Third Edition, July 2011 1243380000/02/07.11 Please note: This document and any further product information - if available - can be downloaded at the internet link: http://www.weidmueller.com/downloads Copyright Notice Copyright © 2011 Weidmüller Interface GmbH & Co. KG All rights reserved.
-
Page 2: Package Checklist
Overview The IE-SW-BL05-5GT is equipped with 5 Gigabit Ethernet ports, making it an ideal and economical solution for demanding, high bandwidth Gigabit Ethernet applications. In addition, the built-in relay warning function alerts system administrators when power failures or port breaks occur. The switches have... - Page 3 Panel Layout of IE-SW-BL05-5GT 1. Grounding screw 2. Terminal block for power input (PWR1, PWR2) and relay output 3. Power input PWR1 LED 4. Power input PWR2 LED 5. Fault LED 6. TP port’s 10/10/1000 Mbps LED 7. Port number 8.
-
Page 4: Mounting Dimensions (Unit = Mm)
Mounting Dimensions (unit = mm) DIN-Rail Mounting The aluminum DIN-rail attachment plate should already be fixed to the back panel of the Ethernet Switch when you take it out of the box. If you need to reattach the DIN-rail attachment plate, make sure the stiff metal spring is situated towards the top, as shown in the figures below. -
Page 5: Atex Information
STEP 2: 6.0 mm Mounting the Ethernet S witch on the wall requires 4 screws. Use the switch, wit h wall mount plates attached, as a guide to mark the corr ect locations of the 4 screws. The heads of the screws sho uld be less than 6.0 m m in 3.5 mm... -
Page 6: Wiring Requirements
Wiring Requirements WARNING Safety First! Turn the power off before disconnecting modules or wires. Th proper power supply voltage is listed on the product label. Check the voltage of your power source to make sure you are using the correct voltage. Do NOT use a voltage greater than what is specified on the product label. -
Page 7: Wiring The Alarm Contact
Wiring the Alarm Contact The Alarm Contact consists of the two middle contacts of the terminal blo ck on the Ethernet Switch top panel. You may refer to the next section for detaile instructions on how to connect the wires to the terminal block conne ctor, and how to attach the terminal block connector to the terminal block receptor. -
Page 8: Communication Connections
Communication C onnections IE-SW-BL05-5GT has 5 10/100/10 BaseT(X) Ethernet ports 10/100/1000BaseT(X ) Ethernet Port Connection The 10/100/1000BaseT(X) ports lo cated on Ethernet Switch’s front panel are used to connect to Ethernet-enabled evices. Most users will choose to configure these ports for Auto MDI /MDI-X mode, in which case the port’s... -
Page 9: Redundant Power Inputs
RJ45 (8-pi to RJ45 -pin) Stra ight-Through Cable Wiring Straight-Through Cable Switch Port NIC Port RJ45 Plug Pin 1 RJ45 onne ctor le Wiring Connecto J45 (8-pin) to RJ45 (8-pin) Cross-Over Cable Wiring Switch Port Cross-Over Cable Switch Port (NIC Port) (NIC Port) RJ45 Plug Pin 1 RJ45... -
Page 10: Dip Switch Settings
DIP Switch Settings ---- The default setting for each DIP switch is OFF. The following table explains the effect of setting the switches to the ON positions. PORT ALARM DIP Switch Setting Description Enables broadcast storm protection Disables broadcast storm protection ---- Enables jumbo frame function refers to Jumbo... -
Page 11: Led Indicators
LED Indicators The front panel of the E thern et Switch contains several LED indicators. The function of each LED is desc ribed in the table below. Color State Description Power is being supplied to power input PWR1 AMBER PWR1 Power is not being supplied to power input PWR1 Power is being supplied to power input... -
Page 12: Auto-Negotiation And Speed Sensing
Auto-Negotiation and Speed Sensing The Ethernet Switch RJ45 Ethernet ports independently support auto-negotiation for transmission speeds of 10 Mbps, 1 00 Mbps, and 1000 Mbps, with operati on according to th e IEEE802.3 standard. This means that som e nod es cou be operating at 10 Mbps, while at the sam time, other nodes are oper ating... - Page 13 Regulatory Approvals Safety UL508 Hazardous Location UL/cUL Class I, Division 2, Groups A, B, C, and ATEX Class I, Zone 2, Ex nC nL I IC T4 FCC Part 15, CISPR (EN55022) c lass A EN61000-4-2 (ESD), Level 3 EN61000-4-3 (RS), Level 3 EN61000-4-4 (EFT), Level 3 EN61000-4-5 (Surge), Level 3 EN61000-4-6 (CS), Level 3...
