Enclosure Dimensions for:
SMP10C12XX
SMP10PMC12XX
15.5" x 12" x 4.5" (393.7mm x 304.8mm x 114.3mm)
4.5"
(114.3mm)
1.25"
(31.75mm)
1.5"
(38.1mm)
2.0"
(50.8mm)
2.0"
(50.8mm)
5.0"
(127.0mm)
1.25"
(31.75mm)
SMP1012Xseries
All manuals and user guides at all-guides.com
1.5"
4.615"
(38.1mm)
(117.22mm)
1.1"
(27.94mm)
0.91"
(23.114mm)
1.5"
4.615"
(38.1mm)
(117.22mm)
4.615"
1.5"
(117.22mm)
(38.1mm)
12.23"
(310.64mm)
(27.94mm)
(27.94mm)
4.615"
1.5"
(38.1mm)
(117.22mm)
1.75"
(44.45mm)
1.375"
(34.925mm)
1.125"
(28.575mm)
4.5"
(114.3mm)
1.1"
0.91"
(23.114mm)
15.5"
(393.7mm)
0.79"
1.1"
(20.06mm)
1.75"
(44.45mm)
1.25"
(31.75mm)
1.5"
(38.1mm)
5.0"
(127.0mm)
1.25"
(31.75mm)
