MTS9300A Telecom Power (Ooredoo, Indonesia,
MTS9304A-HD2002)
User Manual
Step 3 Loosen the screws on the UIM05B1 panel, pull the handle until it is engaged, and
take out the UIM05B1.
Figure 4-3 Removing the UIM05B1
Step 4 Install the new UIM05B1.
Step 5 Install the cables based on the recorded information.
Step 6 Disconnect the ground cable from the ESD wrist strap, and remove the ESD wrist
strap and ESD gloves.
----End
Follow-up Procedure
Put the replaced component in an ESD box or bag and return it to the local
warehouse.
4.3.3 Replacing a Rectifier
Prerequisites
●
●
Protect yourself from being burnt when moving the rectifier because the rectifier
has a high temperature.
Procedure
Step 1 Put on protective gloves.
Step 2 Push the locking latch at the right side of the panel towards the left.
Step 3 Gently draw the handle outwards, and then remove the rectifier from the subrack.
Issue 06 (2021-10-13)
You have obtained a pair of protective gloves and the cabinet door key.
The new rectifier is intact.
CA UTION
Copyright © Huawei Technologies Co., Ltd.
4 Maintenance
52
