Figure 4-4 Removing a rectifier
Step 4 Push the locking latch on the new rectifier towards the left, and pull out the
handle.
Step 5 Place the new rectifier at the entry to the correct slot.
Step 6 Gently slide the converter into the slot along guide rails until it is engaged. Close
the handle, and push the locking latch towards the right to lock the handle.
Figure 4-5 Installing a rectifier
Step 7 Take off protective gloves.
----End
Follow-up Procedure
Pack the removed component, and return it to local warehouse.

4.3.4 Replacing a Circuit Breaker

Prerequisites
The new circuit breaker is intact.
