MTS9300A Telecom Power (Ooredoo, Indonesia,
MTS9304A-HD2002)
User Manual
Item
Installation mode
Application
Environment
Figure 2-2 MTS9304A-HD2002 (01074838) interior
(1) Door status sensor
(4) Ground bar
Issue 06 (2021-10-13)
MTS9304A-HD2002
(01074838)
Installed on a floor
It can be used in Class C environments and cannot be used
in Class D environments.
NO TE
● Class C environments refer to sea environments or outdoor land environments (with
simple shielding measures) near pollution sources. If a site is near a pollution source, it
is at most 3.7 km away from salt water, such as the sea and salt lakes, 3 km away from
heavy pollution sources, such as smelteries, coal mines, and thermal power plants, 2 km
away from medium pollution sources, such as chemical, rubber, and galvanization
industries, and 1 km away from light pollution sources, such as packing houses,
tanneries, and boiler rooms.
● Class D environment: It refers to the environment within 500 m away from the ocean.
Copyright © Huawei Technologies Co., Ltd.
(2) AC power distribution box
(5) Space for temperature and
humidity sensor
2 Product Overview
MTS9304A-HD2002
(01074838-001)
(3) Power subrack
(6) Space for customer
equipment
18
