INSTALLATION: DRAWERS / STORAGE / ELECTRICAL CONNECTIONS (GHSSCD336LB.5744A)
Ambient Model GHSSCD336LB.5744A Is
Shown In Below Illustration
5. Ambient Drawers / Ambient Storage Areas
• Entire case (including rear section) is ambient.
• Drawers and storage areas are provided.
• See illustration below.
Drawers
--- Model GHSSCD336LB.5744A Rear ---
6. Electrical Connections
Field Access Box / LED Driver
> Note: Lower front panel must be lifted up and off.
See INSTALLATION: REMOVAL FROM SKID,
REMOVING VERTICAL LOWER FRONT PANELS
section in this manual for more in-depth illustrations
on hook/slot panel removal design.
• Stub-up connections are at rear of lower front
panel.
• To access, remove lower front panel (no screw
removal required).
•
Note: Wiring process must be performed by
certified electrician only.
Drawers
Storage
Lower Front
Panel
9
Field Access
Box
--- Model GHSSCD336LB.5744A Front ---
LED Driver
