8
6
10
Picture D
D PICTURE COMPONENTS
STEP 4
Take out the handle assembly (6), tension spring assembly (8), and pull rope assembly(10) Two pieces, as shown in Figure F
align and install the corresponding holes, and the completed result is the component D. At this point, the entire product
components are completed.
7
