Picture B
B PICTURE COMPONENTS
STEP 2
Ia. Take out the main frame assembly (1), 3 pieces of ring bolt d10 * 55 (66) (11), 1 piece of hexagon head bolt M10 * 55 (13)
and hexagon nut M10 (12). Align with the components in Figure A as shown in Figure B, align and install the corresponding
holes, and tighten the related screws. The result is B components
