- Page 1 Operating instructions NLSW®45-3 SIL1 24 V AC/DC, 230 V AC...
- Page 2 Version 1...
- Page 4 +49 2058 916 900 0 - info@seikom-electronic.com - www.seikom-electronic.com page 2...
-
Page 5: Table Of Contents
Operating instructions NLSW®45-3 SIL1 Contents Contents ............................3 1. SAFETY INSTRUCTIONS ......................4 2. GENERAL INFORMATION ......................4 2.1 Proper use..............................4 2.2 Functional principle............................4 3. TECHNICAL DATA........................5 4. INSTALLATION AND COMMISSIONING..................6 4.1 Installation conditions..........................6 4.2 Electrical connections ..........................6 4.3 Setting the switching point ........................7 4.4 Instructions for commissioning........................7 5. -
Page 6: Safety Instructions
Operating instructions NLSW®45-3 SIL1 1. SAFETY INSTRUCTIONS Read the product description before using the device. M a k e s u r e that the product is fully suitable for your application. Incorrect or improper use can lead to malfunctions of the device or to undesirable effects on your application. -
Page 7: Technical Data
Operating instructions NLSW®45-3 SIL1 3. TECHNICAL DATA Type NLSW®45-3 SIL1 Operating voltage 24 V AC/DC 230 V AC 50/60 Hz Article no. 77029SIL1 63377SIL1 Voltage tolerance ± 5% ± 6% Overvoltage category Signal display voltage Green LED Power consumption max. 3 VA 4.5 VA Ambient temperature Device... -
Page 8: Installation And Commissioning
Operating instructions NLSW®45-3 SIL1 4. INSTALLATION AND COMMISSIONING Installation and commissioning must be carried out by authorized and qualified personnel. The connection to the main supply (L, N) must be made via a protected circuit breaker with standard fuses. The general VDE regulations must always be observed (VDE 0100, VDE 0113, VDE 0160). If the potential-free contact is connected to a safety extra-low voltage, the connecting cables must be sufficiently insulated up to the terminal, as otherwise the double insulation to the mains voltage side may be impaired. -
Page 9: Setting The Switching Point
Operating instructions NLSW®45-3 SIL1 4.3 Setting the switching point The relationship between air velocity and change in resistance is not linear. In the lower range (small flows), the change in resistance is very large. In the upper range, the change in resistance is always smaller for the same flow changes. -
Page 10: Maintenance Instructions
Operating instructions NLSW®45-3 SIL1 5. MAINTENANCE INSTRUCTIONS The air flow sensor should be serviced at regular intervals, i.e. the air flow sensor should be cleaned when used in heavily contaminated media. The following procedure is recommended: Dismantling the air flow sensor ▪... -
Page 11: Eu Declaration Of Conformity
Operating instructions NLSW®45-3 SIL1 7. EU DECLARATION OF CONFORMITY +49 2058 916 900 0 - info@seikom-electronic.com - www.seikom-electronic.com Page 9... - Page 12 Operating instructions NLSW®45-3 SIL1 +49 2058 916 900 0 - info@seikom-electronic.com - www.seikom-electronic.com page 10...
