Redundancy
Both power connectors are linked 1-on-1 to the
internal power supply of the T1. If 1 power supply
would fail, the other takes over without delay time.
When redundancy is not required, it is sufficient to
o
use 1 power connector. When the T1 is flipped 180
,
the connectors can be used without alteration. Fig. 3
illustrates the location of the power supply connectors.
Piggy back
connector for
maintenance
Power
activities
Bus cable in
Fig. 3 Structure of the T1
