Setting/Adjustment of the Wireless Unit

Parameter settings of the Base

Change the settings of each parameter as necessary.

System setting

Change the settings of each parameter as necessary.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
System setting parameters
Classification
(1) I/O mapping
(2) Diagnostic allocation
(3) Max. Remote units
Time of Wireless
(4)
communication timeout
System
(5) Power Transmission Level
Setting
(6) Wireless signal
(7) Protocol
(8) Time Information
•The protocol version is set to V.2.0 by default; to use EX600-W series Remote devices,
change the protocol version to V.1.0 before pairing them.
Parameter
Auto
None/Simple/ Advanced
15 /31/63 Remotes
100/200/500/1,000 msec
/2,000/5,000 msec
High/Middle/Low
Active/Idle
V.1.0/V.2.0
-
Set value
-39-
(9)
Initial value Note
Auto
Advanced
15 Remotes
Activated only when
500 msec
protocol V.2.0 is used
Activated only when
High
protocol V.2.0 is used
Active
V.2.0
Activated only when
-
protocol V.2.0 is used
Doc.DOC1069999
