Description:
The ASE730 is a broadband white light test source in the 1510nm to 1610nm regions. It has been designed to satisfy the
demand for longer wavelength (1550nm to 1600nm) test equipment for the emerging L-band market.
This device takes advantage of an erbium doped fluoride fiber that is pumped with a single 1480nm laser diode to
produce 30mW (14.77dBm) of white light. The very broad output spectrum has been achieved by utilizing an erbium
doped fluoride fiber pumped by a single laser diode, this design allows for a higher degree of power and wavelength
stability than conventional silica fibers. The output fiber is a standard SMF28 silica fiber.
Technical Specifications:
Table 1 - Specifications
Parameter
Operation Wavelength
Output Power
Stability – Short term (15min)*
Stability – Long term (48 Hr)
Output Fiber Type
Operating Temperature
Storage Temperature
* after 1 hour warm-up period
C & L BAND ASE LIGHT SOURCE
POWER
O
|
Power ON Switch
6626-D02 Rev. B 8/15/05
Min
1530
30
0
-10
Power ON Indicator
Figure 1 - Front Panel Features
Figure 2 - Rear Panel Features
Page 3 of 7
Typical
Max
1610
32.5
35
+/- 0.001
+/- 0.05
SMF28
40
45
ASE730
FC/PC Adapter
EXT MON
Manufactured by
Newton, NJ USA
115V/230V Switch
Unit
nm
mW
dB
dB
°C
°C
OUTPUT
Protective Cap
115VAC 50-60 Hz
160mA Type T Fuse
230VAC 50-60 Hz
LINE SELECT
FUSE
AC Input /
Fuse Drawer
