Installation quick-start guide
Mounting, top
View of the mounting rail
Mounting, bottom
View with the door of the DC Wallbox open
8
iONiX 25_DC-Wallbox_D00461_00_Q_XXEN/11.2023
Mounting rail for attachment to the wall
1: Retaining lug, top (outside)
2: Spacer for attachment points, bottom (outside)
1: Attachment points, bottom (inside)
