• If the installation site is outside a protected area of a building, additional lightning protection measures
must be taken.
• The ceiling height of the installation site should be at least 2.30 m.
• Protect the power cord for the supply as follows:
– Residual current circuit breaker (RCD type A)
– Overvoltage protection, type 1 (SPD type 1, normally part of the building power supply)
– ≤ 50 A circuit breaker
– Earth terminal at least 10 mm² Cu
– Permissible cross-section of the connection in the Wallbox: max. 10 mm² flexible with ferrule;
max. 16 mm² rigid conductor
• Permissible network types: TT, TN-S, TN-C-S
• Connectivity: Ethernet, GSM/LTE, WiFi
ADVICE
Before establishing the electrical connection, ensure that the device is dry (e.g. no condensation). If
necessary, the device can be dried using an external hot air blower (T
1.4

Mechanical installation

1.4.1

Tools

Tools needed
• Lifting table: Adjustment range from 570 mm to 700 mm
• Lifting aid (designed for at least 90 kg)
• Impact drilling machine
• Masonry drill bit Ø 10 mm
• Spirit level
• Pencil
• Rubber mallet
• Open-end spanner (width across flats 12 mm) and/or socket spanner with extension
and corresponding socket
CAUTION
Injury
Using a lifting aid for wall mounting
Lifting the DC Wallbox without an aid
iONiX 25_DC-Wallbox_D00461_00_Q_XXEN/11.2023
iONiX Light 25 Wallbox
iONiX Medium 25 Wallbox
iONiX Supreme 25 Wallbox
=50°).
