Installation quick-start guide
In addition to this quick-start guide for mechanical and electrical installation, additional documents, such as
the manual, are available for download on the product page of the device.
Product
page
Indication of important instructions
DANGER
Indicates a high risk of danger that will result in death or serious injury if not avoided.
WARNING
Indicates a medium risk of danger that can lead to death or serious injury if not avoided.
CAUTION
Indicates a low-level risk that can result in minor or moderate injury or damage to property if not
avoided.
ADVICE
Indicates important facts that are not associated with the risk of immediate injury. They can lead to
malfunctions in situations in which the device is handled incorrectly, for example.
1.1
Scope of delivery
The DC Wallbox is delivered as a complete device, upright, in a package on a pallet. Included in the scope of
delivery:
• 1x DC Wallbox including cable cover
• 1x mounting rail
• 5x screws (8 x 60) according to DIN 571 (type 107 with associated plugs for mounting on a concrete wall)
• 1x key set with 3x keys
• 1x key tag
• 1x screw for the cable cover
• 1x TPE Uni insert (seal for power supply)
• 1x washer
• 1x nut
• 1x drilling template
• 1x Installation quick-start guide
ADVICE
For a concrete wall, use the screws supplied. If the wall is not a concrete wall, the appropriate screws
must be used.
Mounting
video
iONiX 25_DC-Wallbox_D00461_00_Q_XXEN/11.2023
iONiX Light 25 Wallbox
iONiX Medium 25 Wallbox
iONiX Supreme 25 Wallbox
3
