Installation quick-start guide
10. Use the operator securing mechanism to seal the door
11. Restore the power supply
The display becomes active after a few minutes
ADVICE
After you start the DC Wallbox, drying is started by default and can last up to 30 min. While this is
happening, charging is not possible.
If you are sure that the DC Wallbox is dry, you can stop the drying process in the configuration
settings of the charge controller (see chapter "Initial commissioning" in the manual).
It can be assumed that the DC Wallbox is dry if one of the following criteria applies:
• The device was stored in a dry place with a room temperature higher than the ambient
temperature during installation. The time between leaving the warehouse and starting the DC
Wallbox may not exceed 1 hour.
• No more than 1 hour has passed since the last drying.
• Visual inspection of the interior of the DC Wallbox does not reveal any moisture.
1.6

Commissioning

For commissioning of the DC Wallbox, refer to chapter "Initial commissioning" in the manual.
1.7

Technical data

ADVICE
This document contains only an excerpt of the most important tabular data. The complete array of
tabular data can be found in the manual.
Tabular data
General
Dimensions (H x W x D)
With cable cover
Without cable cover
Weight
12 iONiX 25_DC-Wallbox_D00461_00_Q_XXEN/11.2023
Figure 1-7: Position of operator
securing mechanism
2,094 mm × 726 mm × 270 mm
1,540 mm × 726 mm × 270 mm
Approx. 90 kg
