Dimensions of infrastructure of network connection
Dimensions in mm
A
Wall
C
Interface area
D
Infrastructure cable (cable length above ground at least 1000 mm)
G
Outline DC Wallbox
1.4.3
Procedure
ADVICE
Wearing safety shoes and gloves is recommended.
Holding surfaces
Surface
Surfaces that may be touched
Surfaces that may not be touched
Top view
Colour
Green
White
iONiX 25_DC-Wallbox_D00461_00_Q_XXEN/11.2023
iONiX Light 25 Wallbox
iONiX Medium 25 Wallbox
iONiX Supreme 25 Wallbox
Enclosure element
Top and bottom
Door (glass)
Side parts (plastic in some cases)
Status and ambient lighting
Status and lighting mast
7
