4.1.4

Analogue Inputs

Analogue sensors (terminal strip X1)
Input signal sensor 1/2

Power supply

Connection
Position feedback EMS 17 ... 22 (terminal strip X7)
Input signal

Power supply

Connection
Servo center transducer, remote precision adjustment EFE 1
(terminal strip X10)
Input signal
Power supply
Current supply
Connection
Servo center transducer OMG 4, OMG 8, CK 37
(terminal strip X10)
Input signal
Power supply
Connection
ekr 500 digital Unit Touch – Installation and Commissioning Manual
Technical Specifications
0 ... 10 V⎓ or 0 ... 20 mA
(can be switched using
DIL switch S7)
24 V⎓ / max. Σ 0.3 A
Internally on the spring-cage
terminal block
0 ... 10 V⎓
+12 V⎓
Internally on the spring-cage
terminal block
0 ... 10 V⎓
+12 V⎓
Max. Σ +12 V⎓: 150 mA
Internally on the spring-cage
terminal block
According to Namur
specifications
According to Namur
specifications
Internally on the spring-cage
terminal block
