Accessories; Nameplates - BST ekr 500 digital Installation And Commissioning Manual

3.6

Accessories

3.7

Nameplates

For accessories and the order address, see Accessories and Spare
Parts, page 154.
The nameplates are located on the top of the controller and on
the rear of the control panel.
The nameplate displayed is only an example. Please obtain the
current data from the nameplate attached to the product.
Fig. 10: Example of a nameplate
Pos.
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
ekr 500 digital Unit Touch – Installation and Commissioning Manual
Field Meaning
Address Manufacturer address
RoHS designation
Certificates
CE designation
IDC Serial number
Type Type designation
Ver Hardware version
U Operating voltage
Date of manufacture
PC
(Calendar week / Year)
IP Protection type
I Nominal current consumption
Data matrix code,
Code
Content = 30 digit serial number (IDC)
