Quick configuration Guide for
Login instructions:
In order to log in to the Modulator NMS port, please set your PC's NIC Ethernet card
to the following IP address: 192.168.0.100.
Access Modulator GUI by typing derail IP address
Login /password – admin/admin
1 1
3
Apply button for any parameters changes, to save it
permanently – Go to CONFIGURATION Tab and SAVE
Ver.2023
https://thorbroadcast.com
H-HDPerformux- 8/16/24
Encoder Channels
Video Audio encoding
setup
for CH 1-8 , 9-16, 17-24
4 Channel Input HDMI Setting Selection
800-521-8467
192.168.0.136
in to the browser
sales@thorfiber.com
Video Bitrate
5
setup
HDMI Video Input
Lock indicator
6
Turns Green if the
signal is detected
6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Thor Broadcast H-HDPerformux- 8
Summary of Contents for Thor Broadcast H-HDPerformux- 8
- Page 1 Quick configuration Guide for H-HDPerformux- 8/16/24 Login instructions: In order to log in to the Modulator NMS port, please set your PC's NIC Ethernet card to the following IP address: 192.168.0.100. Access Modulator GUI by typing derail IP address 192.168.0.136 in to the browser Login /password –...
- Page 2 TS Config Program Information setting This page controls which HDMI Input CH 1-24 or ASI or USB (in MPTS ) are selected and moved to the IPTV outputs By default all 24 channels are selected Stream Select SPTS ( single program transport stream or MPTS (Multiprogram transport stream selection) HDMI inputs encoded transport streams...
- Page 3 IP Stream Setup ENABLE ON/OFF Multicast or unicast IP address Port number Total Bit rate – need to be > than Video Bit rate UDP or RTP or RTSP selection Null Packet ON/OFF Function Apply IPTV streaming is sent out from the data port and can be tested using VLC player. UDP syntax example is udp://@224.2.2.2:2001 RTP syntax example is rtp://@224.2.2.2:2001 RTSP syntax example is rtsp://( DATA IP ADRESS):5000/1-4...
