Embedded Computing Platform
Hardware Platforms for Intelligent Edge Computing
LEC-2580
User Manual
Date of Release: 2024-01-19
1
Version: 1.7
Version: 2.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEC-2580 and is the answer not in the manual?

Questions and answers

Related Manuals for Lanner LEC-2580

Summary of Contents for Lanner LEC-2580

  • Page 1 Embedded Computing Platform Hardware Platforms for Intelligent Edge Computing LEC-2580 User Manual Version: 1.7 Date of Release: 2024-01-19 Version: 2.5...
  • Page 2 - assumed to be qualified in the servicing of computer equipment, such as professional system integrators, or service personnel and technicians. The latest version of this document can be found on Lanner’s official website, available either through the product page or through the Lanner Download Center page with a login account and password.
  • Page 3 Modified LTE Wireless Network Module model name Copyright and Trademarks This document is copyrighted © 2024 by Lanner Electronics Inc. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice.
  • Page 4 221 新北市汐止區 service@ls-china.com.cn 大同路二段 173 號 7 樓 T: +886-2-8692-6060 F: +886-2-8692-6101 contact@lannerinc.com Canada Lanner Electronics Inc. Lanner Electronics Canada Ltd 47790 Westinghouse Drive 3160A Orlando Drive Fremont, CA 94539 Mississauga, ON T: +1-855-852-6637 L4V 1R5 Canada F: +1-510-979-0689 T: +1 877-813-2132 sales_us@lannerinc.com...
  • Page 5 Acknowledgment Intel® and Intel® Atom® are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries. Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp. All other product names or trademarks are properties of their respective owners. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules.
  • Page 6 Safety Guidelines Follow these guidelines to ensure general safety: Keep the chassis area clear and dust-free during and after installation. Do not wear loose clothing or jewelry that could get caught in the chassis. Fasten your tie or scarf and roll up your sleeves. Wear safety glasses if you are working under any conditions that might be hazardous to your eyes.
  • Page 7 Periodically check the resistance value of the antistatic strap, which should be between 1 and 10 megohms (Mohms). Sécurité de fonctionnement L’équipement électrique génère de la chaleur. La température ambiante peut ne pas être adéquate pour refroidir l’équipement à une température de fonctionnement acceptable sans circulation adaptée. Vérifiez que votre site propose une circulation d’air adéquate.
  • Page 8 Electrical Safety Instructions Before turning on the device, ground the grounding cable of the equipment. Proper grounding (grounding) is very important to protect the equipment against the harmful effects of external noise and to reduce the risk of electrocution in the event of a lightning strike.

  • Page 9: Table Of Contents

    Internal Jumpers & Connectors ......................17 Jumper Settings & Connector Pinout (Motherboard) ................18 CHAPTER 4: HARDWARE SETUP ............25 Accessing the Inside of LEC-2580 ....................... 25 Installing SO-DIMM Memory ......................26 Installing mSATA and Mini-PCIe Module ..................... 27 Installing LTE Wireless Network Module .................... 28 Installing Disk Drives ........................

  • Page 10: Chapter 1: Product Overview

    RS-232/422/485 serial ports, four USB 3.0, two USB 2.0 ports and two HDMI ports. For networking communications, the LEC-2580 offers six 10/100/1000 Mbps Ethernet ports while the LEC-2580P, a variant of the LEC-2580, comes with two 10/100/1000 Mbps Ethernet ports and four PoE ports for even greater flexibility.

  • Page 11: System Specifications

    System Specifications Intel® Core™ i7-6600U/i5-6300U/i3- 6100U Frequency 2.6GHz/2.4GHz/2.3GHz Processor Core Number BIOS AMI 128Mbit SPI Flash BIOS Fanless Technology 2x DDR3L 1333/1600MHz SO-DIMM sockets supporting up to 16GB Memory Max. Capacity 16 GB Socket 2x 204-pin SODIMM Controller Intel® HD Graphics Graphic HDMI 2x HDMI, 3840 x 2160 @24Hz or 2560 x 1600 @60Hz...
  • Page 12 Power Consumption (Full Load) Optional AC to DC, AC 90V to 240V Input, DC Power Adaptor 24V/2.5A 60W Adapter Operating 0°C~60°C (LEC-2580 models) (Note) Temperature 0°C~50°C (LEC-2580P models) Storage Temperature -20°C~70°C Environment Relative Humidity 5%~95% (Non-condensing) IEC 60068-2-64, 0.5Grms, Random 5 ~500 Hz, 40...

  • Page 13: Chapter 2: System Overview

    CHAPTER 2: SYSTEM OVERVIEW Mechanical Drawing Unit: mm...

  • Page 14: Block Diagram

    Block Diagram...

  • Page 15: Front I/Os

    Front I/Os Description 6x 10/100/1000 mbps RJ-45 LAN ports LAN Port LAN3-LAN6 are PoE ports USB Port 4x USB3.0 Type-A ports in dual double-stacked form 2x LED for Power-on status (Green) and Storage access status (Yellow); LED Indicator 2x LED for 3G & WiFi communication access Reset Button 1x Reset button Antenna...

  • Page 16: Rear I/Os

    Rear I/Os Description Power Input 1x 2-pin terminal block, support DC +24V input Power Button 1x 2-pin terminal block for remote power on/off COM Port 4x D-sub COM Ports with RS-232/422/485 signals USB Port 2x USB 2.0 Type-A Ports in double-stacked form HDMI Port 2x HDMI Ports...

  • Page 17: Chapter 3: Board Layout

    CHAPTER 3: BOARD LAYOUT Internal Jumpers & Connectors JSPI1 LAN1-6 USB2 USB1 JTPM1 SATAPWR1-2 SATA1- MSATA1 MPCIE2 DIMM2 MPCIE1 DIMM1 POE1 JLPC JVGA1 ATX1 USB3 JME1 HDMI1-2 COM1-2 JCMOS1...

  • Page 18: Jumper Settings & Connector Pinout (Motherboard)

    Jumper Settings & Connector Pinout (Motherboard) HDMI1: High-Definition Multimedia Interface connector Pin No. Description Pin No. Description DATA2+ DATA2- DATA1+ DATA1- DATA0+ DATA0- CLK+ CLK- DDC CLK DDC DAT HDMI_VCC HDMI2: High-Definition Multimedia Interface connector Pin No. Description Pin No. Description DATA2+ DATA2-...
  • Page 19 LAN1-6: LAN Connectors (RJ-45 connectors with LED) at 10/100/1000Mbps for Ethernet connectivity. LAN3 to LAN6 are PoE ports. Pin No. Description TXD+ MD0+ TXD- MD0- MD1+ MD2+ MD2- MD1- MD3+ MD3- 10-/100-/1000+ 10+/100+/1000- Active LED+ Active LED-(yellow) USB1-2: 4 x USB3.0 Type-A Connectors in dual double-stacked form Pin No.
  • Page 20 COM1/COM2: 4 x DB-9 COM ports with RS-232/422/485 signals (COM1-4 on the panel) Signal Signal Data Carrier Detect (DCDA#) Data Set Ready (DSRA#) Receive Data (RXDA) Request To Send (RTSA#) Transmit Data (TXDA) Clear To Send (CTSA#) Data Terminal Ready (DTRA#) Ring Indicator (RIA#) Pin Assignments for RS-232/422/485 RS-232...
  • Page 21 MPCIE1: mini-PCIe slot with USB signals and SIM card reader (Full Size) for wireless module Description Description WAKE# +3.3V RSVD RSVD +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP RSVD RSVD W_DISABLE# PERST# PERn0 +3.3V PERp0 MPCIE1 +1.5V SMB_CLK PETn0 SMB_DATA PETp0...
  • Page 22 MPCIE2: half-sized mini-PCIe slot with PCIe and USB signals for wireless modules Description Description WAKE# +3.3V RSVD RSVD +1.5V CLKREQ# UIM_PWR UIM_DATA REFCLK- UIM_CLK REFCLK+ UIM_RESET UIM_VPP RSVD RSVD W_DISABLE# PERST# PERn0 +3.3V PERp0 +1.5V SMB_CLK PETn0 SMB_DATA PETp0 USB_D+ USB_D- +3.3V +3.3V...
  • Page 23 MSATA1: mSATA Mini Slot for Storage Device (half-sized form) Description Description +3.3V SATA_RXp +3.3V SATA_RXn SATA_TXn SATA_TXp +3.3V +3.3V +3.3V...
  • Page 24 DCIN1: DC Power Input through 2-pin 5.0mm Phoenix Connector DESCRIPTION DC_IN (-) DC_IN (24V) JCMOS1: Clear CMOS Setting Short Pins Description CMOS1 CMOS1 Normal (Default) Normal(Def) Clear CMOS Clear CMOS JME1: Flash ME (Manageability Engine) Short Pins Description Normal (Default) Normal(Def) Flash ME Flash ME...

  • Page 25: Chapter 4: Hardware Setup

     Please wear ESD protected gloves before conducting the following steps.  Do NOT pile items on top of the system to prevent damages due to this improper use. Lanner is not liable for damages caused by improper use of the product.

  • Page 26: Installing So-Dimm Memory

    Installing SO-DIMM Memory The system is designed with two SO-DIMM sockets supporting up to 16GB DDR3L 1333/1600MHz. Please follow the steps below for proper installations. 1. Locate the SO-DIMM sockets on the motherboard. 2. Select the socket for installing the module. Align the memory module’s key with the SO-DIMM socket’s key. 3.

  • Page 27: Installing Msata And Mini-Pcie Module

    Installing mSATA and Mini-PCIe Module The system provides one mSATA mini socket and two mini-PCIe sockets (one full-sized and another half-sized) for storage and wireless modules. Please follow the steps below for installations. 1. Locate the mSATA and the mini-PCIe sockets. 2.

  • Page 28: Installing Lte Wireless Network Module

    Installing LTE Wireless Network Module The mini-PCIe socket of the system is compatible with LTE wireless network module. Please follow the steps below for installations. 1. Locate the mini-PCIe sockets. 2. Align the mechanical notches between the module and the socket. 3.

  • Page 29: Installing Disk Drives

    Installing Disk Drives The system supports 1 x dual 2.5” SATA HDD/SSD drive bay as data storage (SSD is recommended due to heat and vibration concerns). Please follow the steps below for installation. 1. Locate the dual 2.5” SATA HDD/SSD drive bay at the back of the bottom compartment. 2.

  • Page 30: Wall Mounting

    Wall Mounting The system can be mounted on a flat surfaced wall. Please take the following into considerations when mounting the system onto the wall. 1. Ensure the wall brackets are properly fixed onto the chassis, as illustrated in the drawings below. 2.

  • Page 31: Rack Mounting

    Rack Mounting This system is designed to be installed on a server rack using a rack mount shelf kit. For purchasing a compatible rack mount shelf kit, please reach out to our sales representative. Contents of Rack Mount Shelf Kit This kit comes with screws for the assembly parts Power Adapter Bracket x2 ...
  • Page 32 1. To start, please power off the system and remove the power cord. 2. Remove the four rubber pads at the bottom compartment, and replace them with the bottom panel screws supplied along with the kit.
  • Page 33 3. Assemble the shelves and mounting ears as shown in the picture below with 8 screws on each side. Do not fix the screws to the full extent and leave them a bit loose in order for you to adjust the shelves later. Front Right Left...
  • Page 34 5. Insert the power adapter and lock the adapter bracket(s) onto the shelf using the provided screw(s). Power Adapter for non POE-supported model: For the power adapter for the non POE-supported model, please respectively lock a bracket on the front and the rear shelf, the positions of which are shown in the picture below.
  • Page 35 Power Adapter for POE-supported model: For the power adapter for the POE-supported model, please lock only one bracket on the front shelf, the position of which is shown in the picture below.
  • Page 36 5. After the power adapter is firmly secured on the shelf, make sure all the screws on each part are tightly and securely screwed. 6. Carefully arrange the cable before you install this assembly into the server rack. Power Adapter for non POE-supported model: Power Adapter for POE-supported model:...

  • Page 37: Appendix 1: Watchdog Timer

    Appendix 1: Watchdog Timer A watchdog timer is a hardware component designed to automatically monitor and address system malfunctions by resetting the processor if issues arise. It operates on a countdown mechanism, starting from a predetermined value set by the software, and decreasing to zero. The software routinely resets this counter to prevent it from reaching zero.
