INSTRUCTION MANUAL
For Nauticam Cinema Gear Set for
Canon RF 15-30mm F4.5-6.3 IS STM
PN# 16345
FORWORD
Thank you for your purchase of a NAUTICAM
product.
At NAUTICAM, we pride ourselves in the ability to
recognize the requirements of professional as well
as amateur underwater photographers and fulfill
them through the innovative designs of our
products. We strive to achieve a high level of
user-friendliness by allowing stress-free
installation and easy operation of all important
functions of the camera.
Each product is individually inspected and water
pressure tested to ensure optimum quality.
Please read this manual carefully before using the
product, this will maximize its performance as well
as its lifetime.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 16345 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nauticam 16345

Summary of Contents for Nauticam 16345

  • Page 1 PN# 16345 FORWORD Thank you for your purchase of a NAUTICAM product. At NAUTICAM, we pride ourselves in the ability to recognize the requirements of professional as well as amateur underwater photographers and fulfill them through the innovative designs of our products.
  • Page 2 NAUTICAM does not hold responsibility for damage, of any nature, to any equipment used with and/or placed within our products. NAUTICAM accepts no liability for any loss of captured images or the inability to capture images even if it is due to the malfunctioning of our products.
  • Page 3 IDENTIFICATION OF PARTS Plastic C-ring for zoom gear Plastic C-ring for focus gear CR1530-Z Cinema Zoom Gear CR1530-F Cinema Focus Gear...
  • Page 4 MOUNT THE GEARS ON A LENS 1. Insert the plastic C-ring for zoom gear as shown and place it over the lens. 2 Insert the plastic C-ring for focus gear as shown and place it over the lens and plastic C-ring for zoom gear. 3.
  • Page 5 MOUNT THE GEARS ON A LENS 4. Insert the zoom gear on a plastic C-ring for the zoom gear until it reaches the flange of the plastic C-ring. 5. To remove the Cinema Gear Set for Canon RF 15-30mm F4.5-6.3 IS STM, reverse the above steps.
  • Page 6 CONTROL THE GEAR 1. The Cinema Gear Set for Canon RF 15-30mm F4.5-6.3 IS STM can be controlled by zoom/focus knobs of the housing. After mount the camera and lens (with gear installed) on the housing, confirm that the zoom/focus knobs operates correctly.
  • Page 7 SPECIFICATIONS #16345 Nauticam Cinema Gear Set for Canon RF 15-30mm F4.5-6.3 IS STM Zoom gear : DIA102mm × 19.0mm Dimensions: Focus gear : DIA102mm × 41.0mm Type: Zoom and focus gears Compatible Canon RF 15-30mm F4.5-6.3 IS lens: Remark: Nauticam supports only e-manuals. Please download corresponding product manuals on google drive https://bit.ly/Nauticammanual, or contact us for e-...
