Nauticam 16347 Instruction Manual

Cinema gear set for canon rf 24-50mm f/4.5-6.3 is stm lens
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Current as of 07/18/2023
INSTRUCTION MANUAL
for Cinema Gear Set for Canon RF
24-50mm f/4.5-6.3 IS STM Lens
PN# 16347
FORWORD
Thank you for your purchase of a NAUTICAM
product.
At NAUTICAM, we pride ourselves in the ability to
recognize the requirements of professional as well
as amateur underwater photographers and fulfill
them through the innovative designs of our
products. We strive to achieve a high level of user-
friendliness by allowing stress-free installation and
easy operation of all important functions of the
camera.
Each product is individually inspected and water
pressure tested to ensure optimum quality.
Please read this manual carefully before using the
product, this will maximize its performance as well
as its lifetime.
