Booster IP 1-4, 3-pin
Connecting the power input will turn the device on. The power indictor will light up to indicate that the
device has power. The DMX indicator will light up to indicate that the device is receiving a DMX signal.
In the event that the power indicator or DMX indicator does not light up, see 6. Troubleshooting on page
16 for more information.

Power Linking of Multiple Devices

This device supports power linking. Power can be relayed to another device via the power OUT
connector. Note that the input and the output connectors have different designs: one type cannot be
connected to the other.
Power linking of multiple devices must be carried out only by instructed or skilled persons.
WARNING
Incorrect power linking may lead to overload of the electrical circuit and result in serious
injuries and damage of property.
To prevent overload of the electrical circuit, when power linking multiple devices:
● Use cables with sufficient current-carrying capacity. The power cable supplied with the device is not
suitable for power linking of multiple devices.
● Make sure that the total current draw of the device and all connected devices does not exceed the
rated capacity of the power cables and the circuit breaker.
● Do not link more devices on one power link than the maximum recommended number.
Maximum recommended number of devices:
● at 100–240 V: 15 devices Booster IP 1-4, 3-pin

RDM Information

This device supports RDM. Refer to 5.6.2. Supported RDM PIDs (Parameter IDs) for more information.

RDM Details

● Responder:
● Manufacturer's ID:
● Manufacturer Label:
● Model Description:
● Model ID:
● Device Label:
Note:
An RDM responder ID consists of 3 parts:
● 1 part – 4 digits – Manufacturer's ID
st
● 2 part – 3 digits – Model ID
nd
● 3 part – 5 digits – Unique ID
rd
The RDM responder IDs of all products of Highlite International start with the same 4 digits. The first 7 digits
of the RDM responder ID for each model are the same. The last 5 digits are different for each device.
Product code: 50796
29B4:0C5xxxxx
Showtec
Showtec
Booster IP 1-4
197
Booster IP 1-4
14
